Collection: Gears - Worm
Gears -> WormThere are 6 products in the sub-categories of Gears - Worm. Browse the Gears - Worm products table. To narrow down the selection, please choose a sub-category from the links below.
Gears - Worm - 24DP
A selection of 24DP Worm Gears. This is the main category in...
Gears - Worm - 32DP
A selection of 32DP Worm Gears. This is the main category in...
Gears - Worm - 48DP
A selection of 48DP Worm Gears. This is the main category in...
Gears - Worm - Module 1.0
A selection of Module 1.0 Worm Gears. This is the main category...
Category Details
This category includes various types of worm gears.
- Worms and Gears must be chosen from the same pitch, direction and lead angle match. DP is Diametrical Pitch, which is an imperial standard.
- A single start worm and gear will provide a ratio equivalent to the number of teeth on the gear. A double start worm and gear will provide a ratio of half the number of teeth on the gear.
- If there is no matching worm for a stocked gear, please contact us for a special procurement. An expanded range may be available on special order. Please enquire.
Small Parts & Bearings
Additional resources:
A more comprehensive listing may be found in the Gears - Worm category on the MBA Minibearings main store.
