Gears - Worm - Module 1.0

2 Products in this selection
  • Worms and Gears must be chosen from the same pitch, direction and lead angle match. DP is Diametrical Pitch, which is an imperial standard.
  • A single start worm and gear will provide a ratio equivalent to the number of teeth on the gear. A double start worm and gear will provide a ratio of half the number of teeth on the gear.
  • If there is no matching worm for a stocked gear, please contact us for a special procurement.
  • This is the main category in this series
Additional resources:

A more comprehensive listing may be found on the MBA Minibearings main store at Gears - Worm - Module 1.0.
Pitch Teeth Lead Angle Direction Bore (B) Overall Length (l) Indicative
Module 1.0
20
3 Deg 35 Min
mm 		Right Hand
6.000
20.000
Worm Gears - Module 1.0 x 20 3 Deg 35 Min
Material: Nylon (Polyamide 6/6)    Pitch Diameter (C): 20.00 mm    Face Width (fw): 10.000 mm    Bore Type: Finished    Hub Diameter (Dh): 16.00 mm    Locking Type: No Set Screw
Part Number: WG1R-100-020-060-NY Worm Gears - Pitch Module 1.0 20 - 3 Deg 35 Min - Nylon (Polyamide 6/6)
1 Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$20.00 AUD
$38.00 AUD $20.00 AUD
Each
Pitch Teeth Lead Angle Direction Indicative
Module 1.0
20
3 Deg 35 Min
mm 		Right Hand
Worm Gears - Module 1.0 x 20 3 Deg 35 Min
Material: Nylon (Polyamide 6/6)    Bore (B): 6.000    Overall Length (l): 20.000    Pitch Diameter (C): 20.00 mm    Face Width (fw): 10.000 mm    Bore Type: Finished    Hub Diameter (Dh): 16.00 mm    Locking Type: No Set Screw
Part Number: WG1R-100-020-060-NY Worm Gears - Pitch Module 1.0 20 - 3 Deg 35 Min - Nylon (Polyamide 6/6)
1 Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$20.00 AUD
$38.00 AUD $20.00 AUD
Each
Module 1.0
50
3 Deg 35 Min
mm 		Left Hand
8.000
18.000
Worm Gears - Module 1.0 x 50 3 Deg 35 Min
Material: Aluminium Bronze    Pitch Diameter (C): 50.00 mm    Face Width (fw): 10.000 mm    Bore Type: Finished    Hub Diameter (Dh): 30.00 mm    Locking Type: Set Screw
Part Number: WG1L-100-050-080-ALB Worm Gears - Pitch Module 1.0 50 - 3 Deg 35 Min - Aluminium Bronze
1 Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$50.00 AUD
$95.00 AUD $50.00 AUD
Each
Module 1.0
50
3 Deg 35 Min
mm 		Left Hand
Worm Gears - Module 1.0 x 50 3 Deg 35 Min
Material: Aluminium Bronze    Bore (B): 8.000    Overall Length (l): 18.000    Pitch Diameter (C): 50.00 mm    Face Width (fw): 10.000 mm    Bore Type: Finished    Hub Diameter (Dh): 30.00 mm    Locking Type: Set Screw
Part Number: WG1L-100-050-080-ALB Worm Gears - Pitch Module 1.0 50 - 3 Deg 35 Min - Aluminium Bronze
1 Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$50.00 AUD
$95.00 AUD $50.00 AUD
Each
