Collection: Retaining Rings - External - Circlips - Standard

Retaining Rings (With Images)

External

Circlips

Tabbed

677 Products in this selection

This is a combined category of products from Standard Circlips External Retaining Rings. Use the filters in the table below, or the category tree to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
Anderton Cross Reference PDF
Circlips PDF Catalogue
Circlip Tools

Shaft Diameter (Ds)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip ID (A)	Radial Wall (S) min/max	Groove Width (W)
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm		0.74 mm
Material: Carbon Steel Zinc Plated Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 10.92 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00635-CZY (10 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings 50 units (500 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $2.95 AUD Regular price Sale price $2.95 AUD Unit price per Per 10 View the product page first if you are unsure.
Shaft Diameter (Ds)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip ID (A)	Indicative Image
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm
Material: Carbon Steel Zinc Plated Groove Width (W): 0.74 mm Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 10.92 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00635-CZY (10 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings 50 units (500 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $2.95 AUD Regular price Sale price $2.95 AUD Unit price per Per 10 View the product page first if you are unsure.
CCE-00635-CZY (10 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Carbon Steel Zinc Plated CCE-00635-CZY (10 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Carbon Steel Zinc Plated Regular price $2.95 AUD Regular price Sale price $2.95 AUD Unit price per 50 Available Now
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm		0.74 mm
Material: Carbon Steel Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 10.92 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00635-C (20 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings 18 units (360 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $4.86 AUD Regular price Sale price $4.86 AUD Unit price per Per 20 View the product page first if you are unsure.
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm
Material: Carbon Steel Groove Width (W): 0.74 mm Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 10.92 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00635-C (20 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings 18 units (360 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $4.86 AUD Regular price Sale price $4.86 AUD Unit price per Per 20 View the product page first if you are unsure.
CCE-00635-C (20 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Carbon Steel CCE-00635-C (20 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Carbon Steel Regular price $4.86 AUD Regular price Sale price $4.86 AUD Unit price per 18 Available Now
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm		0.74 mm
Material: Beryllium Copper Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 10.92 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00635-B (50 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $65.68 AUD Regular price Sale price $65.68 AUD Unit price per Per 50 View the product page first if you are unsure.
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm
Material: Beryllium Copper Groove Width (W): 0.74 mm Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 10.92 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00635-B (50 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $65.68 AUD Regular price Sale price $65.68 AUD Unit price per Per 50 View the product page first if you are unsure.
CCE-00635-B (50 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Beryllium Copper CCE-00635-B (50 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Beryllium Copper Regular price $65.68 AUD Regular price Sale price $65.68 AUD Unit price per Out of stock! Backorder Now
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm		0.74 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 11.43 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00635-S15 (5 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings 56 units (280 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $10.68 AUD Regular price Sale price $10.68 AUD Unit price per Per 5 View the product page first if you are unsure.
6.35 mm	0.64 mm +/-0.038	5.84 mm +/-0.051	5.72 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.74 mm Clearance on Shaft (C1): 11.43 mm Clearance in Groove (C1): 11.43 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.81 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00635-S15 (5 Pcs) Circlips - 6.35 mm x 0.64 mm x 5.84 mm / Retaining Rings 56 units (280 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $10.68 AUD Regular price Sale price $10.68 AUD Unit price per Per 5 View the product page first if you are unsure.
CCE-00635-S15 (5 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Stainless PH15-7 Mo CCE-00635-S15 (5 Pcs) --- Circlips - 6.35 mm x 0.64 mm x 5.84 mm Stainless PH15-7 Mo Regular price $10.68 AUD Regular price Sale price $10.68 AUD Unit price per 56 Available Now
7.00 mm	0.80 mm +0.00/-0.06	6.70 mm +0.00/-0.05	6.50 mm		0.90 mm
Material: Carbon Steel Clearance on Shaft (C1): 13.50 mm Clearance in Groove (C1): 12.90 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.50 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00700-C (50 Pcs) Circlips - 7 mm x 0.8 mm x 6.7 mm / Retaining Rings 9 units (450 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.41 AUD Regular price Sale price $5.41 AUD Unit price per Per 50 View the product page first if you are unsure.
7.00 mm	0.80 mm +0.00/-0.06	6.70 mm +0.00/-0.05	6.50 mm
Material: Carbon Steel Groove Width (W): 0.90 mm Clearance on Shaft (C1): 13.50 mm Clearance in Groove (C1): 12.90 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.50 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00700-C (50 Pcs) Circlips - 7 mm x 0.8 mm x 6.7 mm / Retaining Rings 9 units (450 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.41 AUD Regular price Sale price $5.41 AUD Unit price per Per 50 View the product page first if you are unsure.
CCE-00700-C (50 Pcs) --- Circlips - 7 mm x 0.8 mm x 6.7 mm Carbon Steel CCE-00700-C (50 Pcs) --- Circlips - 7 mm x 0.8 mm x 6.7 mm Carbon Steel Regular price $5.41 AUD Regular price Sale price $5.41 AUD Unit price per 9 Available Now
7.00 mm	0.80 mm +0.00/-0.06	6.70 mm +0.00/-0.05	6.50 mm		0.90 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 13.50 mm Clearance in Groove (C1): 12.90 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.50 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00700-S15 (2 Pcs) Circlips - 7 mm x 0.8 mm x 6.7 mm / Retaining Rings 55 units (110 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.86 AUD Regular price Sale price $5.86 AUD Unit price per Per 2 View the product page first if you are unsure.
7.00 mm	0.80 mm +0.00/-0.06	6.70 mm +0.00/-0.05	6.50 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.90 mm Clearance on Shaft (C1): 13.50 mm Clearance in Groove (C1): 12.90 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.50 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00700-S15 (2 Pcs) Circlips - 7 mm x 0.8 mm x 6.7 mm / Retaining Rings 55 units (110 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.86 AUD Regular price Sale price $5.86 AUD Unit price per Per 2 View the product page first if you are unsure.
CCE-00700-S15 (2 Pcs) --- Circlips - 7 mm x 0.8 mm x 6.7 mm Stainless PH15-7 Mo CCE-00700-S15 (2 Pcs) --- Circlips - 7 mm x 0.8 mm x 6.7 mm Stainless PH15-7 Mo Regular price $5.86 AUD Regular price Sale price $5.86 AUD Unit price per 55 Available Now
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm		0.74 mm
Material: Carbon Steel Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00701-C (250 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $118.77 AUD Regular price Sale price $118.77 AUD Unit price per Per 250 View the product page first if you are unsure.
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm
Material: Carbon Steel Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00701-C (250 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $118.77 AUD Regular price Sale price $118.77 AUD Unit price per Per 250 View the product page first if you are unsure.
CCE-00701-C (250 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Carbon Steel CCE-00701-C (250 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Carbon Steel Regular price $118.77 AUD Regular price Sale price $118.77 AUD Unit price per Out of stock! Backorder Now
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm		0.74 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00701-S15 (2 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings 15 units (30 pcs) Available \| Backorders for more can be expected around Fri, Mar 28, 2025 Regular price $4.68 AUD Regular price Sale price $4.68 AUD Unit price per Per 2 View the product page first if you are unsure.
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00701-S15 (2 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings 15 units (30 pcs) Available \| \| Backorders for more can be expected around Fri, Mar 28, 2025 Regular price $4.68 AUD Regular price Sale price $4.68 AUD Unit price per Per 2 View the product page first if you are unsure.
CCE-00701-S15 (2 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Stainless PH15-7 Mo CCE-00701-S15 (2 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Stainless PH15-7 Mo Regular price $4.68 AUD Regular price Sale price $4.68 AUD Unit price per 15 Available Now
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm		0.74 mm
Material: Carbon Steel Zinc Plated Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00701-CZY (5 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings 19 units (95 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $3.86 AUD Regular price Sale price $3.86 AUD Unit price per Per 5 View the product page first if you are unsure.
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm
Material: Carbon Steel Zinc Plated Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00701-CZY (5 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings 19 units (95 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $3.86 AUD Regular price Sale price $3.86 AUD Unit price per Per 5 View the product page first if you are unsure.
CCE-00701-CZY (5 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Carbon Steel Zinc Plated CCE-00701-CZY (5 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Carbon Steel Zinc Plated Regular price $3.86 AUD Regular price Sale price $3.86 AUD Unit price per 19 Available Now
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm	B (Square Ends) mm	0.74 mm
Material: Beryllium Copper Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00701-B (125 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $364.68 AUD Regular price Sale price $364.68 AUD Unit price per Per 125 View the product page first if you are unsure.
7.01 mm	0.64 mm +/-0.051	6.48 mm +/-0.051	6.35 mm
Material: Beryllium Copper Radial Wall (S) min/max: B (Square Ends) mm Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.19 mm Clearance in Groove (C1): 11.68 mm Min. Extension (n): 0.89 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00701-B (125 Pcs) Circlips - 7.01 mm x 0.64 mm x 6.48 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $364.68 AUD Regular price Sale price $364.68 AUD Unit price per Per 125 View the product page first if you are unsure.
CCE-00701-B (125 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Beryllium Copper CCE-00701-B (125 Pcs) --- Circlips - 7.01 mm x 0.64 mm x 6.48 mm Beryllium Copper Regular price $364.68 AUD Regular price Sale price $364.68 AUD Unit price per Out of stock! Backorder Now
7.14 mm	0.64 mm +/-0.051	6.63 mm +/-0.051	6.50 mm		0.74 mm
Material: Carbon Steel Clearance on Shaft (C1): 12.45 mm Clearance in Groove (C1): 12.45 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.84 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00714-C (20 Pcs) Circlips - 7.14 mm x 0.64 mm x 6.63 mm / Retaining Rings 29 units (580 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $4.95 AUD Regular price Sale price $4.95 AUD Unit price per Per 20 View the product page first if you are unsure.
7.14 mm	0.64 mm +/-0.051	6.63 mm +/-0.051	6.50 mm
Material: Carbon Steel Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.45 mm Clearance in Groove (C1): 12.45 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.84 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00714-C (20 Pcs) Circlips - 7.14 mm x 0.64 mm x 6.63 mm / Retaining Rings 29 units (580 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $4.95 AUD Regular price Sale price $4.95 AUD Unit price per Per 20 View the product page first if you are unsure.
CCE-00714-C (20 Pcs) --- Circlips - 7.14 mm x 0.64 mm x 6.63 mm Carbon Steel CCE-00714-C (20 Pcs) --- Circlips - 7.14 mm x 0.64 mm x 6.63 mm Carbon Steel Regular price $4.95 AUD Regular price Sale price $4.95 AUD Unit price per 29 Available Now
7.14 mm	0.64 mm +/-0.051	6.63 mm +/-0.051	6.50 mm		0.74 mm
Material: Carbon Steel Zinc Plated Clearance on Shaft (C1): 12.45 mm Clearance in Groove (C1): 12.45 mm Min. Extension (n): 0.84 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00714-CZY (500 Pcs) Circlips - 7.14 mm x 0.64 mm x 6.63 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $121.50 AUD Regular price Sale price $121.50 AUD Unit price per Per 500 View the product page first if you are unsure.
7.14 mm	0.64 mm +/-0.051	6.63 mm +/-0.051	6.50 mm
Material: Carbon Steel Zinc Plated Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.45 mm Clearance in Groove (C1): 12.45 mm Min. Extension (n): 0.84 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00714-CZY (500 Pcs) Circlips - 7.14 mm x 0.64 mm x 6.63 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $121.50 AUD Regular price Sale price $121.50 AUD Unit price per Per 500 View the product page first if you are unsure.
CCE-00714-CZY (500 Pcs) --- Circlips - 7.14 mm x 0.64 mm x 6.63 mm Carbon Steel Zinc Plated CCE-00714-CZY (500 Pcs) --- Circlips - 7.14 mm x 0.64 mm x 6.63 mm Carbon Steel Zinc Plated Regular price $121.50 AUD Regular price Sale price $121.50 AUD Unit price per Out of stock! Backorder Now
7.14 mm	0.64 mm +/-0.051	6.63 mm +/-0.051	6.50 mm		0.74 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 12.45 mm Clearance in Groove (C1): 12.45 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.84 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00714-S15 (5 Pcs) Circlips - 7.14 mm x 0.64 mm x 6.63 mm / Retaining Rings 15 units (75 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $9.95 AUD Regular price Sale price $9.95 AUD Unit price per Per 5 View the product page first if you are unsure.
7.14 mm	0.64 mm +/-0.051	6.63 mm +/-0.051	6.50 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.74 mm Clearance on Shaft (C1): 12.45 mm Clearance in Groove (C1): 12.45 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.84 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00714-S15 (5 Pcs) Circlips - 7.14 mm x 0.64 mm x 6.63 mm / Retaining Rings 15 units (75 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $9.95 AUD Regular price Sale price $9.95 AUD Unit price per Per 5 View the product page first if you are unsure.
CCE-00714-S15 (5 Pcs) --- Circlips - 7.14 mm x 0.64 mm x 6.63 mm Stainless PH15-7 Mo CCE-00714-S15 (5 Pcs) --- Circlips - 7.14 mm x 0.64 mm x 6.63 mm Stainless PH15-7 Mo Regular price $9.95 AUD Regular price Sale price $9.95 AUD Unit price per 15 Available Now
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm		0.74 mm
Material: Beryllium Copper Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00794-B Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings 100 Available \| Backorders for more can be expected around Sun, Jan 26, 2025 Regular price $3.32 AUD Regular price Sale price $3.32 AUD Unit price per Each View the product page first if you are unsure.
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm
Material: Beryllium Copper Groove Width (W): 0.74 mm Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00794-B Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings 100 Available \| \| Backorders for more can be expected around Sun, Jan 26, 2025 Regular price $3.32 AUD Regular price Sale price $3.32 AUD Unit price per Each View the product page first if you are unsure.
CCE-00794-B --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Beryllium Copper CCE-00794-B --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Beryllium Copper Regular price $3.32 AUD Regular price Sale price $3.32 AUD Unit price per 100 Available Now
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm		0.74 mm
Material: Carbon Steel Zinc Plated Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00794-CZY (100 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $30.41 AUD Regular price Sale price $30.41 AUD Unit price per Per 100 View the product page first if you are unsure.
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm
Material: Carbon Steel Zinc Plated Groove Width (W): 0.74 mm Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00794-CZY (100 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $30.41 AUD Regular price Sale price $30.41 AUD Unit price per Per 100 View the product page first if you are unsure.
CCE-00794-CZY (100 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Carbon Steel Zinc Plated CCE-00794-CZY (100 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Carbon Steel Zinc Plated Regular price $30.41 AUD Regular price Sale price $30.41 AUD Unit price per Out of stock! Backorder Now
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm		0.74 mm
Material: Carbon Steel Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00794-C (20 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings 31 units (620 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $4.95 AUD Regular price Sale price $4.95 AUD Unit price per Per 20 View the product page first if you are unsure.
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm
Material: Carbon Steel Groove Width (W): 0.74 mm Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00794-C (20 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings 31 units (620 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $4.95 AUD Regular price Sale price $4.95 AUD Unit price per Per 20 View the product page first if you are unsure.
CCE-00794-C (20 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Carbon Steel CCE-00794-C (20 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Carbon Steel Regular price $4.95 AUD Regular price Sale price $4.95 AUD Unit price per 31 Available Now
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm		0.74 mm
Material: Carbon Steel Zinc Plated Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00794-CZ (100 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $30.41 AUD Regular price Sale price $30.41 AUD Unit price per Per 100 View the product page first if you are unsure.
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm
Material: Carbon Steel Zinc Plated Groove Width (W): 0.74 mm Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00794-CZ (100 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $30.41 AUD Regular price Sale price $30.41 AUD Unit price per Per 100 View the product page first if you are unsure.
CCE-00794-CZ (100 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Carbon Steel Zinc Plated CCE-00794-CZ (100 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Carbon Steel Zinc Plated Regular price $30.41 AUD Regular price Sale price $30.41 AUD Unit price per Out of stock! Backorder Now
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm		0.74 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00794-S15 (5 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings 51 units (255 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $10.95 AUD Regular price Sale price $10.95 AUD Unit price per Per 5 View the product page first if you are unsure.
7.94 mm	0.64 mm +/-0.051	7.37 mm +/-0.051	7.14 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.74 mm Clearance on Shaft (C1): 13.72 mm Clearance in Groove (C1): 13.21 mm Min. Extension (n): 0.91 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00794-S15 (5 Pcs) Circlips - 7.94 mm x 0.64 mm x 7.37 mm / Retaining Rings 51 units (255 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $10.95 AUD Regular price Sale price $10.95 AUD Unit price per Per 5 View the product page first if you are unsure.
CCE-00794-S15 (5 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Stainless PH15-7 Mo CCE-00794-S15 (5 Pcs) --- Circlips - 7.94 mm x 0.64 mm x 7.37 mm Stainless PH15-7 Mo Regular price $10.95 AUD Regular price Sale price $10.95 AUD Unit price per 51 Available Now
8.00 mm	0.80 mm +0.00/-0.06	7.60 mm +0.00/-0.05	7.40 mm		0.90 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 14.70 mm Clearance in Groove (C1): 14.00 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.60 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00800-S15 (10 Pcs) Circlips - 8 mm x 0.8 mm x 7.6 mm / Retaining Rings 8 units (80 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $29.77 AUD Regular price Sale price $29.77 AUD Unit price per Per 10 View the product page first if you are unsure.
8.00 mm	0.80 mm +0.00/-0.06	7.60 mm +0.00/-0.05	7.40 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.90 mm Clearance on Shaft (C1): 14.70 mm Clearance in Groove (C1): 14.00 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.60 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00800-S15 (10 Pcs) Circlips - 8 mm x 0.8 mm x 7.6 mm / Retaining Rings 8 units (80 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $29.77 AUD Regular price Sale price $29.77 AUD Unit price per Per 10 View the product page first if you are unsure.
CCE-00800-S15 (10 Pcs) --- Circlips - 8 mm x 0.8 mm x 7.6 mm Stainless PH15-7 Mo CCE-00800-S15 (10 Pcs) --- Circlips - 8 mm x 0.8 mm x 7.6 mm Stainless PH15-7 Mo Regular price $29.77 AUD Regular price Sale price $29.77 AUD Unit price per 8 Available Now
8.00 mm	0.80 mm +0.00/-0.06	7.60 mm +0.00/-0.05	7.40 mm		0.90 mm
Material: Carbon Steel Clearance on Shaft (C1): 14.70 mm Clearance in Groove (C1): 14.00 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.60 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00800-C (50 Pcs) Circlips - 8 mm x 0.8 mm x 7.6 mm / Retaining Rings 27 units (1350 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Per 50 View the product page first if you are unsure.
8.00 mm	0.80 mm +0.00/-0.06	7.60 mm +0.00/-0.05	7.40 mm
Material: Carbon Steel Groove Width (W): 0.90 mm Clearance on Shaft (C1): 14.70 mm Clearance in Groove (C1): 14.00 mm Min. Lug Diameter (h): 1.20 mm Min. Extension (n): 0.60 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00800-C (50 Pcs) Circlips - 8 mm x 0.8 mm x 7.6 mm / Retaining Rings 27 units (1350 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Per 50 View the product page first if you are unsure.
CCE-00800-C (50 Pcs) --- Circlips - 8 mm x 0.8 mm x 7.6 mm Carbon Steel CCE-00800-C (50 Pcs) --- Circlips - 8 mm x 0.8 mm x 7.6 mm Carbon Steel Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per 27 Available Now
8.74 mm	0.64 mm +/-0.051	8.15 mm +/-0.051	7.85 mm		0.74 mm
Material: Stainless PH15-7 Mo Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00874-S15 (5 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.15 mm / Retaining Rings 13 units (65 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $11.05 AUD Regular price Sale price $11.05 AUD Unit price per Per 5 View the product page first if you are unsure.
8.74 mm	0.64 mm +/-0.051	8.15 mm +/-0.051	7.85 mm
Material: Stainless PH15-7 Mo Groove Width (W): 0.74 mm Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Stainless Steel
Part Number: CCE-00874-S15 (5 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.15 mm / Retaining Rings 13 units (65 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $11.05 AUD Regular price Sale price $11.05 AUD Unit price per Per 5 View the product page first if you are unsure.
CCE-00874-S15 (5 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.15 mm Stainless PH15-7 Mo CCE-00874-S15 (5 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.15 mm Stainless PH15-7 Mo Regular price $11.05 AUD Regular price Sale price $11.05 AUD Unit price per 13 Available Now
8.74 mm	0.64 mm +/-0.051	8.15 mm +/-0.051	7.85 mm		0.74 mm
Material: Carbon Steel Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00874-C (20 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.15 mm / Retaining Rings 22 units (440 pcs) Available \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.05 AUD Regular price Sale price $5.05 AUD Unit price per Per 20 View the product page first if you are unsure.
8.74 mm	0.64 mm +/-0.051	8.15 mm +/-0.051	7.85 mm
Material: Carbon Steel Groove Width (W): 0.74 mm Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Lug Diameter (h): 0.99 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Carbon Steel
Part Number: CCE-00874-C (20 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.15 mm / Retaining Rings 22 units (440 pcs) Available \| \| Backorders for more can be expected around Sun, Jan 19, 2025 Regular price $5.05 AUD Regular price Sale price $5.05 AUD Unit price per Per 20 View the product page first if you are unsure.
CCE-00874-C (20 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.15 mm Carbon Steel CCE-00874-C (20 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.15 mm Carbon Steel Regular price $5.05 AUD Regular price Sale price $5.05 AUD Unit price per 22 Available Now
8.74 mm	0.64 mm +/-0.051	8.20 mm +/-0.051	7.85 mm		0.70 mm
Material: Beryllium Copper Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00874-B (1250 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.2 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $3,665.14 AUD Regular price Sale price $3,665.14 AUD Unit price per Per 1250 View the product page first if you are unsure.
8.74 mm	0.64 mm +/-0.051	8.20 mm +/-0.051	7.85 mm
Material: Beryllium Copper Groove Width (W): 0.70 mm Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Berryllium Copper
Part Number: CCE-00874-B (1250 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.2 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Fri, Mar 21, 2025 Regular price $3,665.14 AUD Regular price Sale price $3,665.14 AUD Unit price per Per 1250 View the product page first if you are unsure.
CCE-00874-B (1250 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.2 mm Beryllium Copper CCE-00874-B (1250 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.2 mm Beryllium Copper Regular price $3,665.14 AUD Regular price Sale price $3,665.14 AUD Unit price per Out of stock! Backorder Now
8.74 mm	0.64 mm +/-0.051	8.20 mm +/-0.051	7.85 mm		0.70 mm
Material: Carbon Steel Zinc Plated Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00874-CZY (500 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.2 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Sun, Jan 26, 2025 Regular price $151.14 AUD Regular price Sale price $151.14 AUD Unit price per Per 500 View the product page first if you are unsure.
8.74 mm	0.64 mm +/-0.051	8.20 mm +/-0.051	7.85 mm
Material: Carbon Steel Zinc Plated Groove Width (W): 0.70 mm Clearance on Shaft (C1): 14.48 mm Clearance in Groove (C1): 13.97 mm Min. Extension (n): 0.97 Category: Retaining Rings - External - Circlips - Standard - Zinc Plated
Part Number: CCE-00874-CZY (500 Pcs) Circlips - 8.74 mm x 0.64 mm x 8.2 mm / Retaining Rings Out of Stock Backorder Now \| \| Backorders for more can be expected around Sun, Jan 26, 2025 Regular price $151.14 AUD Regular price Sale price $151.14 AUD Unit price per Per 500 View the product page first if you are unsure.
CCE-00874-CZY (500 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.2 mm Carbon Steel Zinc Plated CCE-00874-CZY (500 Pcs) --- Circlips - 8.74 mm x 0.64 mm x 8.2 mm Carbon Steel Zinc Plated Regular price $151.14 AUD Regular price Sale price $151.14 AUD Unit price per Out of stock! Backorder Now
