Collection: Shafting - Precision Ground - Titanium - High Strength

Shafting (With Images)

Precision Ground

Titanium

High Strength
Ti-Gr2-TA1

14 Products in this selection

Titanium shafting available in oversized and undersized tolerances
Used in critical aircraft structural components. UNS R56400.
Composition Percentage: Al 5.5-6.75, V 3.5-4.5, N 0.05, C 0.08, H 0.015, Fe 0.40, O 0.2, Ti Balance
Grade 5, 6Al-4V, TC4 is a high strength titanium alloy. Tensile Strength 91.5kgf / mm². Yield Strength 84.5kgf / mm². Elongation 10 Percent.
Shaft with undersized tolerances is suitable for use with precision ground bearings wih inner rings. HRC 36. Surface Finish Ra 0.8-1.6 um. Not suitable for running needle bearings directly.
Shaft with oversized tolerances is suitable for pulleys or gears requiring interference fits, or for machining to your required tolerances

Additional resources:
Drill Rod

A more comprehensive listing may be found on the MBA Minibearings main store at Shafting - Precision Ground - Titanium - High Strength.

Diameter (d)	Length (L)	Material	Straightness	Surface Finish
Diameter (d) 3.000 mm - 0.005 / - 0.025 _{(0.118 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0030-0300-T5U (2 Pcs) Precision Ground Shafting - 3x300 mm - Ti-Gr5/TC4 315 units (630 pcs) Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $6.77 AUD Regular price Sale price $6.77 AUD Unit price per Per 2
Diameter (d)	Length (L)	Material	Straightness	Indicative Image
Diameter (d) 3.000 mm - 0.005 / - 0.025 _{(0.118 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0030-0300-T5U (2 Pcs) Precision Ground Shafting - 3x300 mm - Ti-Gr5/TC4 315 units (630 pcs) Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $6.77 AUD Regular price Sale price $6.77 AUD Unit price per Per 2 View the product page first if you are unsure.
0R-0030-0300-T5U (2 Pcs) --- Precision Ground Shafting - 3x300 mm - Ti-Gr5/TC4 0R-0030-0300-T5U (2 Pcs) --- Precision Ground Shafting - 3x300 mm - Ti-Gr5/TC4 Regular price $6.77 AUD Regular price Sale price $6.77 AUD Unit price per 315 Available Now
Diameter (d) 4.000 mm + 0.005 / + 0.030 _{(0.157 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Blue / Black
Part Number: 0R-0040-0300-T5O (2 Pcs) Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 31 units (62 pcs) Available Now \| Item Discontinued - Up to 31 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $3.00 AUD Regular price ~~$5.70 AUD~~ Sale price $3.00 AUD Unit price per Per 2
Diameter (d) 4.000 mm + 0.005 / + 0.030 _{(0.157 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Blue / Black
Part Number: 0R-0040-0300-T5O (2 Pcs) Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 31 units (62 pcs) Available Now \| Item Discontinued - Up to 31 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $3.00 AUD Regular price ~~$5.70 AUD~~ Sale price $3.00 AUD Unit price per Per 2
0R-0040-0300-T5O (2 Pcs) --- Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 Sale 0R-0040-0300-T5O (2 Pcs) --- Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 Regular price $3.00 AUD Regular price ~~$5.70 AUD~~ Sale price $3.00 AUD Unit price per 31 Available Now Sale
Diameter (d) 4.000 mm - 0.005 / - 0.030 _{(0.157 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0040-0300-T5U Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 157 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $4.59 AUD Regular price Sale price $4.59 AUD Unit price per Each
Diameter (d) 4.000 mm - 0.005 / - 0.030 _{(0.157 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0040-0300-T5U Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 157 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $4.59 AUD Regular price Sale price $4.59 AUD Unit price per Each View the product page first if you are unsure.
0R-0040-0300-T5U --- Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 0R-0040-0300-T5U --- Precision Ground Shafting - 4x300 mm - Ti-Gr5/TC4 Regular price $4.59 AUD Regular price Sale price $4.59 AUD Unit price per 157 Available Now
Diameter (d) 4.000 mm - 0.005 / - 0.030 _{(0.157 in.)}	Length (L) 1000 mm _{(39.37 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0040-1000-T5U Precision Ground Shafting - 4x1000 mm - Ti-Gr5/TC4 Out of Stock \| Backorder Now \| Orders can be expected around Mon, Aug 11, 2025 Regular price $11.50 AUD Regular price Sale price $11.50 AUD Unit price per Each
Diameter (d) 4.000 mm - 0.005 / - 0.030 _{(0.157 in.)}	Length (L) 1000 mm _{(39.37 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0040-1000-T5U Precision Ground Shafting - 4x1000 mm - Ti-Gr5/TC4 Out of Stock \| Backorder Now \| Orders can be expected around Mon, Aug 11, 2025 Regular price $11.50 AUD Regular price Sale price $11.50 AUD Unit price per Each View the product page first if you are unsure.
0R-0040-1000-T5U --- Precision Ground Shafting - 4x1000 mm - Ti-Gr5/TC4 0R-0040-1000-T5U --- Precision Ground Shafting - 4x1000 mm - Ti-Gr5/TC4 Regular price $11.50 AUD Regular price Sale price $11.50 AUD Unit price per Out of stock! Backorder Now
Diameter (d) 5.000 mm - 0.005 / - 0.030 _{(0.197 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0050-0300-T5U Precision Ground Shafting - 5x300 mm - Ti-Gr5/TC4 233 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $6.05 AUD Regular price Sale price $6.05 AUD Unit price per Each
Diameter (d) 5.000 mm - 0.005 / - 0.030 _{(0.197 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0050-0300-T5U Precision Ground Shafting - 5x300 mm - Ti-Gr5/TC4 233 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $6.05 AUD Regular price Sale price $6.05 AUD Unit price per Each View the product page first if you are unsure.
0R-0050-0300-T5U --- Precision Ground Shafting - 5x300 mm - Ti-Gr5/TC4 0R-0050-0300-T5U --- Precision Ground Shafting - 5x300 mm - Ti-Gr5/TC4 Regular price $6.05 AUD Regular price Sale price $6.05 AUD Unit price per 233 Available Now
Diameter (d) 5.000 mm - 0.005 / - 0.030 _{(0.197 in.)}	Length (L) 1000 mm _{(39.37 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0050-1000-T5U Precision Ground Shafting - 5x1000 mm - Ti-Gr5/TC4 45 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $18.68 AUD Regular price Sale price $18.68 AUD Unit price per Each
Diameter (d) 5.000 mm - 0.005 / - 0.030 _{(0.197 in.)}	Length (L) 1000 mm _{(39.37 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0050-1000-T5U Precision Ground Shafting - 5x1000 mm - Ti-Gr5/TC4 45 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $18.68 AUD Regular price Sale price $18.68 AUD Unit price per Each View the product page first if you are unsure.
0R-0050-1000-T5U --- Precision Ground Shafting - 5x1000 mm - Ti-Gr5/TC4 0R-0050-1000-T5U --- Precision Ground Shafting - 5x1000 mm - Ti-Gr5/TC4 Regular price $18.68 AUD Regular price Sale price $18.68 AUD Unit price per 45 Available Now
Diameter (d) 6.000 mm - 0.005 / - 0.030 _{(0.236 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0060-0300-T5U Precision Ground Shafting - 6x300 mm - Ti-Gr5/TC4 46 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $6.68 AUD Regular price Sale price $6.68 AUD Unit price per Each
Diameter (d) 6.000 mm - 0.005 / - 0.030 _{(0.236 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0060-0300-T5U Precision Ground Shafting - 6x300 mm - Ti-Gr5/TC4 46 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $6.68 AUD Regular price Sale price $6.68 AUD Unit price per Each View the product page first if you are unsure.
0R-0060-0300-T5U --- Precision Ground Shafting - 6x300 mm - Ti-Gr5/TC4 0R-0060-0300-T5U --- Precision Ground Shafting - 6x300 mm - Ti-Gr5/TC4 Regular price $6.68 AUD Regular price Sale price $6.68 AUD Unit price per 46 Available Now
Diameter (d) 8.000 mm - 0.005 / - 0.036 _{(0.315 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0080-0300-T5U Precision Ground Shafting - 8x300 mm - Ti-Gr5/TC4 38 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each
Diameter (d) 8.000 mm - 0.005 / - 0.036 _{(0.315 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0080-0300-T5U Precision Ground Shafting - 8x300 mm - Ti-Gr5/TC4 38 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each View the product page first if you are unsure.
0R-0080-0300-T5U --- Precision Ground Shafting - 8x300 mm - Ti-Gr5/TC4 0R-0080-0300-T5U --- Precision Ground Shafting - 8x300 mm - Ti-Gr5/TC4 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per 38 Available Now
Diameter (d) 10.000 mm - 0.005 / - 0.036 _{(0.394 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0100-0300-T5U Precision Ground Shafting - 10x300 mm - Ti-Gr5/TC4 29 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $20.32 AUD Regular price Sale price $20.32 AUD Unit price per Each
Diameter (d) 10.000 mm - 0.005 / - 0.036 _{(0.394 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0100-0300-T5U Precision Ground Shafting - 10x300 mm - Ti-Gr5/TC4 29 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $20.32 AUD Regular price Sale price $20.32 AUD Unit price per Each View the product page first if you are unsure.
0R-0100-0300-T5U --- Precision Ground Shafting - 10x300 mm - Ti-Gr5/TC4 0R-0100-0300-T5U --- Precision Ground Shafting - 10x300 mm - Ti-Gr5/TC4 Regular price $20.32 AUD Regular price Sale price $20.32 AUD Unit price per 29 Available Now
Diameter (d) 12.000 mm - 0.005 / - 0.043 _{(0.472 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0120-0300-T5U Precision Ground Shafting - 12x300 mm - Ti-Gr5/TC4 15 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $25.86 AUD Regular price Sale price $25.86 AUD Unit price per Each
Diameter (d) 12.000 mm - 0.005 / - 0.043 _{(0.472 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0120-0300-T5U Precision Ground Shafting - 12x300 mm - Ti-Gr5/TC4 15 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $25.86 AUD Regular price Sale price $25.86 AUD Unit price per Each View the product page first if you are unsure.
0R-0120-0300-T5U --- Precision Ground Shafting - 12x300 mm - Ti-Gr5/TC4 0R-0120-0300-T5U --- Precision Ground Shafting - 12x300 mm - Ti-Gr5/TC4 Regular price $25.86 AUD Regular price Sale price $25.86 AUD Unit price per 15 Available Now
Diameter (d) 14.000 mm - 0.005 / - 0.043 _{(0.551 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0140-0300-T5U Precision Ground Shafting - 14x300 mm - Ti-Gr5/TC4 5 Available Now \| Item Discontinued - Up to 5 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $18.50 AUD Regular price ~~$44.37 AUD~~ Sale price $18.50 AUD Unit price per Each
Diameter (d) 14.000 mm - 0.005 / - 0.043 _{(0.551 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0140-0300-T5U Precision Ground Shafting - 14x300 mm - Ti-Gr5/TC4 5 Available Now \| Item Discontinued - Up to 5 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $18.50 AUD Regular price ~~$44.37 AUD~~ Sale price $18.50 AUD Unit price per Each
0R-0140-0300-T5U --- Precision Ground Shafting - 14x300 mm - Ti-Gr5/TC4 Sale 0R-0140-0300-T5U --- Precision Ground Shafting - 14x300 mm - Ti-Gr5/TC4 Regular price $18.50 AUD Regular price ~~$44.37 AUD~~ Sale price $18.50 AUD Unit price per 5 Available Now Sale
Diameter (d) 15.000 mm - 0.005 / - 0.043 _{(0.591 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0150-0300-T5U Precision Ground Shafting - 15x300 mm - Ti-Gr5/TC4 13 Available Now \| Item Discontinued - Up to 13 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $18.05 AUD Regular price ~~$43.36 AUD~~ Sale price $18.05 AUD Unit price per Each
Diameter (d) 15.000 mm - 0.005 / - 0.043 _{(0.591 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0150-0300-T5U Precision Ground Shafting - 15x300 mm - Ti-Gr5/TC4 13 Available Now \| Item Discontinued - Up to 13 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $18.05 AUD Regular price ~~$43.36 AUD~~ Sale price $18.05 AUD Unit price per Each
0R-0150-0300-T5U --- Precision Ground Shafting - 15x300 mm - Ti-Gr5/TC4 Sale 0R-0150-0300-T5U --- Precision Ground Shafting - 15x300 mm - Ti-Gr5/TC4 Regular price $18.05 AUD Regular price ~~$43.36 AUD~~ Sale price $18.05 AUD Unit price per 13 Available Now Sale
Diameter (d) 16.000 mm - 0.005 / - 0.043 _{(0.63 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0160-0300-T5U Precision Ground Shafting - 16x300 mm - Ti-Gr5/TC4 2 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $43.59 AUD Regular price Sale price $43.59 AUD Unit price per Each
Diameter (d) 16.000 mm - 0.005 / - 0.043 _{(0.63 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0160-0300-T5U Precision Ground Shafting - 16x300 mm - Ti-Gr5/TC4 2 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $43.59 AUD Regular price Sale price $43.59 AUD Unit price per Each View the product page first if you are unsure.
0R-0160-0300-T5U --- Precision Ground Shafting - 16x300 mm - Ti-Gr5/TC4 0R-0160-0300-T5U --- Precision Ground Shafting - 16x300 mm - Ti-Gr5/TC4 Regular price $43.59 AUD Regular price Sale price $43.59 AUD Unit price per 2 Available Now
Diameter (d) 20.000 mm - 0.005 / - 0.052 _{(0.787 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0200-0300-T5U Precision Ground Shafting - 20x300 mm - Ti-Gr5/TC4 3 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $65.23 AUD Regular price Sale price $65.23 AUD Unit price per Each
Diameter (d) 20.000 mm - 0.005 / - 0.052 _{(0.787 in.)}	Length (L) 300 mm _{(11.811 in.)}	Material Ti-Gr5/TC4
Material: Titanium High Strength Ends: Chamfered End Colour Code: Red / Black
Part Number: 0R-0200-0300-T5U Precision Ground Shafting - 20x300 mm - Ti-Gr5/TC4 3 Available Now \| Further orders can be expected around Mon, Aug 11, 2025 Regular price $65.23 AUD Regular price Sale price $65.23 AUD Unit price per Each View the product page first if you are unsure.
0R-0200-0300-T5U --- Precision Ground Shafting - 20x300 mm - Ti-Gr5/TC4 0R-0200-0300-T5U --- Precision Ground Shafting - 20x300 mm - Ti-Gr5/TC4 Regular price $65.23 AUD Regular price Sale price $65.23 AUD Unit price per 3 Available Now
