Collection: Yoke Ends - Threaded

Yoke Ends (With Images)

Threaded

9 Products in this selection

Linkage Connectors
Drop forged steel machined to SAE standards
Also see clevis joints

Effective Lgth (A)	Hub Diameter (B)	Gap (E) +/- 0.38	Width (F) +/- 0.38	Hole Size (G) +0.25	Stud Height (H) (+0.79)
50.800 mm	11.110 mm	7.140 mm	15.88 mm	6.35 mm	19 mm
Housing Diameter (K): 13 mm Thread Size: 1/4-28 UNF (6.35mm)
Part Number: YE-2RS Threaded Yoke Ends - 50.8 mm x 11.11 mm x 7.14 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $25.59 AUD Regular price Sale price $25.59 AUD Unit price per Each View the product page first if you are unsure ->
Effective Lgth (A)	Hub Diameter (B)	Gap (E) +/- 0.38	Width (F) +/- 0.38	Indicative Image
50.800 mm	11.110 mm	7.140 mm	15.88 mm
Hole Size (G) +0.25: 6.35 mm Stud Height (H) (+0.79): 19 mm Housing Diameter (K): 13 mm Thread Size: 1/4-28 UNF (6.35mm)
Part Number: YE-2RS Threaded Yoke Ends - 50.8 mm x 11.11 mm x 7.14 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $25.59 AUD Regular price Sale price $25.59 AUD Unit price per Each View the product page first if you are unsure.
YE-2RS --- Threaded Yoke Ends - 50.8 mm x 11.11 mm x 7.14 mm YE-2RS --- Threaded Yoke Ends - 50.8 mm x 11.11 mm x 7.14 mm Regular price $25.59 AUD Regular price Sale price $25.59 AUD Unit price per Out of stock! Backorder Now
57.150 mm	12.700 mm	8.730 mm	19.05 mm	7.94 mm	21 mm
Housing Diameter (K): 15 mm Thread Size: 5/16-24 UNF
Part Number: YE-3RS Threaded Yoke Ends - 57.15 mm x 12.7 mm x 8.73 mm 4 Available \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $32.77 AUD Regular price Sale price $32.77 AUD Unit price per Each View the product page first if you are unsure ->
57.150 mm	12.700 mm	8.730 mm	19.05 mm
Hole Size (G) +0.25: 7.94 mm Stud Height (H) (+0.79): 21 mm Housing Diameter (K): 15 mm Thread Size: 5/16-24 UNF
Part Number: YE-3RS Threaded Yoke Ends - 57.15 mm x 12.7 mm x 8.73 mm 4 Available \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $32.77 AUD Regular price Sale price $32.77 AUD Unit price per Each View the product page first if you are unsure.
YE-3RS --- Threaded Yoke Ends - 57.15 mm x 12.7 mm x 8.73 mm YE-3RS --- Threaded Yoke Ends - 57.15 mm x 12.7 mm x 8.73 mm Regular price $32.77 AUD Regular price Sale price $32.77 AUD Unit price per 4 Available Now
63.500 mm	15.880 mm	11.110 mm	22.23 mm	9.53 mm	22 mm
Housing Diameter (K): 17 mm Thread Size: 3/8-24 UNF
Part Number: YE-4RS Threaded Yoke Ends - 63.5 mm x 15.88 mm x 11.11 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $31.95 AUD Regular price Sale price $31.95 AUD Unit price per Each View the product page first if you are unsure ->
63.500 mm	15.880 mm	11.110 mm	22.23 mm
Hole Size (G) +0.25: 9.53 mm Stud Height (H) (+0.79): 22 mm Housing Diameter (K): 17 mm Thread Size: 3/8-24 UNF
Part Number: YE-4RS Threaded Yoke Ends - 63.5 mm x 15.88 mm x 11.11 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $31.95 AUD Regular price Sale price $31.95 AUD Unit price per Each View the product page first if you are unsure.
YE-4RS --- Threaded Yoke Ends - 63.5 mm x 15.88 mm x 11.11 mm YE-4RS --- Threaded Yoke Ends - 63.5 mm x 15.88 mm x 11.11 mm Regular price $31.95 AUD Regular price Sale price $31.95 AUD Unit price per Out of stock! Backorder Now
73.030 mm	18.260 mm	12.700 mm	25.40 mm	11.11 mm	25 mm
Housing Diameter (K): 21 mm Thread Size: 7/16-20 UNF
Part Number: YE-5RS Threaded Yoke Ends - 73.03 mm x 18.26 mm x 12.7 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Each View the product page first if you are unsure ->
73.030 mm	18.260 mm	12.700 mm	25.40 mm
Hole Size (G) +0.25: 11.11 mm Stud Height (H) (+0.79): 25 mm Housing Diameter (K): 21 mm Thread Size: 7/16-20 UNF
Part Number: YE-5RS Threaded Yoke Ends - 73.03 mm x 18.26 mm x 12.7 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Each View the product page first if you are unsure.
YE-5RS --- Threaded Yoke Ends - 73.03 mm x 18.26 mm x 12.7 mm YE-5RS --- Threaded Yoke Ends - 73.03 mm x 18.26 mm x 12.7 mm Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Out of stock! Backorder Now
76.200 mm	20.640 mm	14.290 mm	28.58 mm	12.70 mm	29 mm
Housing Diameter (K): 24 mm Thread Size: 1/2-20 UNF
Part Number: YE-6RS Threaded Yoke Ends - 76.2 mm x 20.64 mm x 14.29 mm 2 Available \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $40.50 AUD Regular price Sale price $40.50 AUD Unit price per Each View the product page first if you are unsure ->
76.200 mm	20.640 mm	14.290 mm	28.58 mm
Hole Size (G) +0.25: 12.70 mm Stud Height (H) (+0.79): 29 mm Housing Diameter (K): 24 mm Thread Size: 1/2-20 UNF
Part Number: YE-6RS Threaded Yoke Ends - 76.2 mm x 20.64 mm x 14.29 mm 2 Available \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $40.50 AUD Regular price Sale price $40.50 AUD Unit price per Each View the product page first if you are unsure.
YE-6RS --- Threaded Yoke Ends - 76.2 mm x 20.64 mm x 14.29 mm YE-6RS --- Threaded Yoke Ends - 76.2 mm x 20.64 mm x 14.29 mm Regular price $40.50 AUD Regular price Sale price $40.50 AUD Unit price per 2 Available Now
101.600 mm	28.580 mm	17.460 mm	38.10 mm	15.88 mm	32 mm
Housing Diameter (K): 35 mm Thread Size: 3/4-10 UNC (19.05mm)
Part Number: YE-8SPRS Threaded Yoke Ends - 101.6 mm x 28.58 mm x 17.46 mm 1 Available \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $45.56 AUD Regular price ~~$68.35 AUD~~ Sale price $45.56 AUD Unit price per Each
101.600 mm	28.580 mm	17.460 mm	38.10 mm
Hole Size (G) +0.25: 15.88 mm Stud Height (H) (+0.79): 32 mm Housing Diameter (K): 35 mm Thread Size: 3/4-10 UNC (19.05mm)
Part Number: YE-8SPRS Threaded Yoke Ends - 101.6 mm x 28.58 mm x 17.46 mm 1 Available \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $45.56 AUD Regular price ~~$68.35 AUD~~ Sale price $45.56 AUD Unit price per Each
YE-8SPRS --- Threaded Yoke Ends - 101.6 mm x 28.58 mm x 17.46 mm Sale YE-8SPRS --- Threaded Yoke Ends - 101.6 mm x 28.58 mm x 17.46 mm Regular price $45.56 AUD Regular price ~~$68.35 AUD~~ Sale price $45.56 AUD Unit price per 1 Available Now Sale
106.360 mm	20.640 mm	14.290 mm	28.58 mm	12.70 mm	29 mm
Housing Diameter (K): 24 mm Thread Size: 1/2-20 UNF
Part Number: YE-6BRS Threaded Yoke Ends - 106.36 mm x 20.64 mm x 14.29 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $52.41 AUD Regular price Sale price $52.41 AUD Unit price per Each View the product page first if you are unsure ->
106.360 mm	20.640 mm	14.290 mm	28.58 mm
Hole Size (G) +0.25: 12.70 mm Stud Height (H) (+0.79): 29 mm Housing Diameter (K): 24 mm Thread Size: 1/2-20 UNF
Part Number: YE-6BRS Threaded Yoke Ends - 106.36 mm x 20.64 mm x 14.29 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $52.41 AUD Regular price Sale price $52.41 AUD Unit price per Each View the product page first if you are unsure.
YE-6BRS --- Threaded Yoke Ends - 106.36 mm x 20.64 mm x 14.29 mm YE-6BRS --- Threaded Yoke Ends - 106.36 mm x 20.64 mm x 14.29 mm Regular price $52.41 AUD Regular price Sale price $52.41 AUD Unit price per Out of stock! Backorder Now
125.410 mm	26.990 mm	17.460 mm	34.93 mm	15.88 mm	32 mm
Housing Diameter (K): 30 mm Thread Size: 5/8-18 UNF
Part Number: YE-7RS Threaded Yoke Ends - 125.41 mm x 26.99 mm x 17.46 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $105.68 AUD Regular price Sale price $105.68 AUD Unit price per Each View the product page first if you are unsure ->
125.410 mm	26.990 mm	17.460 mm	34.93 mm
Hole Size (G) +0.25: 15.88 mm Stud Height (H) (+0.79): 32 mm Housing Diameter (K): 30 mm Thread Size: 5/8-18 UNF
Part Number: YE-7RS Threaded Yoke Ends - 125.41 mm x 26.99 mm x 17.46 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $105.68 AUD Regular price Sale price $105.68 AUD Unit price per Each View the product page first if you are unsure.
YE-7RS --- Threaded Yoke Ends - 125.41 mm x 26.99 mm x 17.46 mm YE-7RS --- Threaded Yoke Ends - 125.41 mm x 26.99 mm x 17.46 mm Regular price $105.68 AUD Regular price Sale price $105.68 AUD Unit price per Out of stock! Backorder Now
153.99 mm	31.75 mm	20.64 mm	41.28 mm	19.05 mm	38.10 mm
Housing Diameter (K): 36.51 mm Thread Size: 3/4-16 UNF
Part Number: YE-8RS Threaded Yoke Ends - 153.99 mm x 31.75 mm x 20.64 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $188.68 AUD Regular price Sale price $188.68 AUD Unit price per Each View the product page first if you are unsure ->
153.99 mm	31.75 mm	20.64 mm	41.28 mm
Hole Size (G) +0.25: 19.05 mm Stud Height (H) (+0.79): 38.10 mm Housing Diameter (K): 36.51 mm Thread Size: 3/4-16 UNF
Part Number: YE-8RS Threaded Yoke Ends - 153.99 mm x 31.75 mm x 20.64 mm Out of Stock \| Backorder Now \| Backorders for more can be expected around Wed, Feb 05, 2025 Regular price $188.68 AUD Regular price Sale price $188.68 AUD Unit price per Each View the product page first if you are unsure.
YE-8RS --- Threaded Yoke Ends - 153.99 mm x 31.75 mm x 20.64 mm YE-8RS --- Threaded Yoke Ends - 153.99 mm x 31.75 mm x 20.64 mm Regular price $188.68 AUD Regular price Sale price $188.68 AUD Unit price per Out of stock! Backorder Now
