Collection: Washers - Disc Spring - Standard - Stainless Steel

Washers (With Images)

Disc Spring

Standard

Carbon Steel
Plastic
Stainless Steel

21 Products in this selection

Includes disc springs to DIN 2093 and belleville washers to DIN 6796.
Manufactured under strict quality control to conform to DIN 2093

Small Parts & Bearings

Additional resources:
Disc Spring Washers PDF
Screws

A more comprehensive listing may be found on the MBA Minibearings main store at Washers - Disc Spring - Standard - Stainless Steel.

Nominal OD (A)	Nominal ID (B)	Stock Thickness (C)	Load to flatten	Loaded Height (L1)	Load at L1
Nominal OD (A) 4.76 mm + 0.01 / + 0.07 _{(0.187 in.)}	Nominal ID (B) 2.38 mm + 0.10 / - 0.00 _{(0.094 in.)}	Stock Thickness (C) 0.25 mm _{(0.01 in.)}	Load to flatten 12.41 kg	Loaded Height (L1) 0.30 mm	Load at L1 6.8 kg
Material: Stainless Steel 302/304 (Similar to A2, 18-8) Free Height (E): 0.38 mm Inside Height (D): 0.13 mm
Part Number: W0024-D-005-003-S2 Disc Spring Washers - 4.76x2.38x0.25 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 272 Available Now \| Further orders can be expected around Sat, Sep 27, 2025 Regular price $3.68 AUD Regular price Sale price $3.68 AUD Unit price per Each
Nominal OD (A)	Nominal ID (B)	Stock Thickness (C)	Load to flatten	Indicative Image
Nominal OD (A) 4.76 mm + 0.01 / + 0.07 _{(0.187 in.)}	Nominal ID (B) 2.38 mm + 0.10 / - 0.00 _{(0.094 in.)}	Stock Thickness (C) 0.25 mm _{(0.01 in.)}	Load to flatten 12.41 kg
Material: Stainless Steel 302/304 (Similar to A2, 18-8) Loaded Height (L1): 0.30 mm Load at L1: 6.8 kg Free Height (E): 0.38 mm Inside Height (D): 0.13 mm
Part Number: W0024-D-005-003-S2 Disc Spring Washers - 4.76x2.38x0.25 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 272 Available Now \| Further orders can be expected around Sat, Sep 27, 2025 Regular price $3.68 AUD Regular price Sale price $3.68 AUD Unit price per Each View the product page first if you are unsure.
W0024-D-005-003-S2 --- Disc Spring Washers - 4.76x2.38x0.25 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 W0024-D-005-003-S2 --- Disc Spring Washers - 4.76x2.38x0.25 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 Regular price $3.68 AUD Regular price Sale price $3.68 AUD Unit price per 272 Available Now
Nominal OD (A) 6.00 mm _{(0.236 in.)}	Nominal ID (B) 3.00 mm + 0.10 / - 0.00 _{(0.118 in.)}	Stock Thickness (C) 0.30 mm _{(0.012 in.)}		Loaded Height (L1) 0.34 mm	Load at L1 12.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 0.45 mm Actual ID (Ref): 3.2 mm Inside Height (D): 0.15 mm
Part Number: W0030-D-006-003-S17 (50 Pcs) Disc Spring Washers - 6x3x0.3 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $32.23 AUD Regular price ~~$38.67 AUD~~ Sale price $32.23 AUD Unit price per Per 50
Nominal OD (A) 6.00 mm _{(0.236 in.)}	Nominal ID (B) 3.00 mm + 0.10 / - 0.00 _{(0.118 in.)}	Stock Thickness (C) 0.30 mm _{(0.012 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.34 mm Load at L1: 12.0 kg Free Height (E): 0.45 mm Actual ID (Ref): 3.2 mm Inside Height (D): 0.15 mm
Part Number: W0030-D-006-003-S17 (50 Pcs) Disc Spring Washers - 6x3x0.3 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $32.23 AUD Regular price ~~$38.67 AUD~~ Sale price $32.23 AUD Unit price per Per 50 View the product page first if you are unsure.
W0030-D-006-003-S17 (50 Pcs) --- Disc Spring Washers - 6x3x0.3 mm Standard - Stainless Steel 17-7 PH Sale W0030-D-006-003-S17 (50 Pcs) --- Disc Spring Washers - 6x3x0.3 mm Standard - Stainless Steel 17-7 PH Regular price $32.23 AUD Regular price ~~$38.67 AUD~~ Sale price $32.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 7.94 mm + 0.01 / + 0.07 _{(0.313 in.)}	Nominal ID (B) 3.96 mm + 0.10 / - 0.00 _{(0.156 in.)}	Stock Thickness (C) 0.41 mm _{(0.016 in.)}	Load to flatten 33.48 kg	Loaded Height (L1) 0.53 mm	Load at L1 18.3 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 0.64 mm Inside Height (D): 0.23 mm
Part Number: W0040-D-008-004-S4 (100 Pcs) Disc Spring Washers - 7.94x3.96x0.41 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $15.95 AUD Regular price ~~$19.15 AUD~~ Sale price $15.95 AUD Unit price per Per 100
Nominal OD (A) 7.94 mm + 0.01 / + 0.07 _{(0.313 in.)}	Nominal ID (B) 3.96 mm + 0.10 / - 0.00 _{(0.156 in.)}	Stock Thickness (C) 0.41 mm _{(0.016 in.)}	Load to flatten 33.48 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.53 mm Load at L1: 18.3 kg Free Height (E): 0.64 mm Inside Height (D): 0.23 mm
Part Number: W0040-D-008-004-S4 (100 Pcs) Disc Spring Washers - 7.94x3.96x0.41 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $15.95 AUD Regular price ~~$19.15 AUD~~ Sale price $15.95 AUD Unit price per Per 100 View the product page first if you are unsure.
W0040-D-008-004-S4 (100 Pcs) --- Disc Spring Washers - 7.94x3.96x0.41 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0040-D-008-004-S4 (100 Pcs) --- Disc Spring Washers - 7.94x3.96x0.41 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $15.95 AUD Regular price ~~$19.15 AUD~~ Sale price $15.95 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 8.00 mm _{(0.315 in.)}	Nominal ID (B) 4.00 mm + 0.20 / - 0.00 _{(0.157 in.)}	Stock Thickness (C) 0.30 mm _{(0.012 in.)}		Loaded Height (L1) 0.36 mm	Load at L1 12.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 0.55 mm Actual ID (Ref): 4.2 mm Inside Height (D): 0.25 mm
Part Number: W0040-D-008-003-S17 (50 Pcs) Disc Spring Washers - 8x4x0.3 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $34.59 AUD Regular price ~~$41.51 AUD~~ Sale price $34.59 AUD Unit price per Per 50
Nominal OD (A) 8.00 mm _{(0.315 in.)}	Nominal ID (B) 4.00 mm + 0.20 / - 0.00 _{(0.157 in.)}	Stock Thickness (C) 0.30 mm _{(0.012 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.36 mm Load at L1: 12.0 kg Free Height (E): 0.55 mm Actual ID (Ref): 4.2 mm Inside Height (D): 0.25 mm
Part Number: W0040-D-008-003-S17 (50 Pcs) Disc Spring Washers - 8x4x0.3 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $34.59 AUD Regular price ~~$41.51 AUD~~ Sale price $34.59 AUD Unit price per Per 50 View the product page first if you are unsure.
W0040-D-008-003-S17 (50 Pcs) --- Disc Spring Washers - 8x4x0.3 mm Standard - Stainless Steel 17-7 PH Sale W0040-D-008-003-S17 (50 Pcs) --- Disc Spring Washers - 8x4x0.3 mm Standard - Stainless Steel 17-7 PH Regular price $34.59 AUD Regular price ~~$41.51 AUD~~ Sale price $34.59 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 9.53 mm + 0.01 / + 0.07 _{(0.375 in.)}	Nominal ID (B) 4.76 mm + 0.20 / - 0.00 _{(0.187 in.)}	Stock Thickness (C) 0.51 mm - 0.00 / - 0.08 _{(0.02 in.)}	Load to flatten 49.11 kg	Loaded Height (L1) 0.64 mm	Load at L1 26.8 kg
Material: Stainless Steel 302/304 (Similar to A2, 18-8) Free Height (E): 0.76 mm Inside Height (D): 0.25 mm
Part Number: W0048-D-010-005-S2 Disc Spring Washers - 9.53x4.76x0.51 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 2235 Available Now \| Further orders can be expected around Thu, Aug 21, 2025 Regular price $4.14 AUD Regular price Sale price $4.14 AUD Unit price per Each
Nominal OD (A) 9.53 mm + 0.01 / + 0.07 _{(0.375 in.)}	Nominal ID (B) 4.76 mm + 0.20 / - 0.00 _{(0.187 in.)}	Stock Thickness (C) 0.51 mm - 0.00 / - 0.08 _{(0.02 in.)}	Load to flatten 49.11 kg
Material: Stainless Steel 302/304 (Similar to A2, 18-8) Loaded Height (L1): 0.64 mm Load at L1: 26.8 kg Free Height (E): 0.76 mm Inside Height (D): 0.25 mm
Part Number: W0048-D-010-005-S2 Disc Spring Washers - 9.53x4.76x0.51 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 2235 Available Now \| Further orders can be expected around Thu, Aug 21, 2025 Regular price $4.14 AUD Regular price Sale price $4.14 AUD Unit price per Each View the product page first if you are unsure.
W0048-D-010-005-S2 --- Disc Spring Washers - 9.53x4.76x0.51 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 W0048-D-010-005-S2 --- Disc Spring Washers - 9.53x4.76x0.51 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 Regular price $4.14 AUD Regular price Sale price $4.14 AUD Unit price per 2235 Available Now
Nominal OD (A) 10.00 mm _{(0.394 in.)}	Nominal ID (B) 5.00 mm + 0.20 / - 0.00 _{(0.197 in.)}	Stock Thickness (C) 0.40 mm _{(0.016 in.)}		Loaded Height (L1) 0.48 mm	Load at L1 21.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 0.70 mm Actual ID (Ref): 5.2 mm Inside Height (D): 0.30 mm
Part Number: W0050-D-010-004-S17 (50 Pcs) Disc Spring Washers - 10x5x0.4 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $37.14 AUD Regular price ~~$44.56 AUD~~ Sale price $37.14 AUD Unit price per Per 50
Nominal OD (A) 10.00 mm _{(0.394 in.)}	Nominal ID (B) 5.00 mm + 0.20 / - 0.00 _{(0.197 in.)}	Stock Thickness (C) 0.40 mm _{(0.016 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.48 mm Load at L1: 21.0 kg Free Height (E): 0.70 mm Actual ID (Ref): 5.2 mm Inside Height (D): 0.30 mm
Part Number: W0050-D-010-004-S17 (50 Pcs) Disc Spring Washers - 10x5x0.4 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $37.14 AUD Regular price ~~$44.56 AUD~~ Sale price $37.14 AUD Unit price per Per 50 View the product page first if you are unsure.
W0050-D-010-004-S17 (50 Pcs) --- Disc Spring Washers - 10x5x0.4 mm Standard - Stainless Steel 17-7 PH Sale W0050-D-010-004-S17 (50 Pcs) --- Disc Spring Washers - 10x5x0.4 mm Standard - Stainless Steel 17-7 PH Regular price $37.14 AUD Regular price ~~$44.56 AUD~~ Sale price $37.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 10.00 mm _{(0.394 in.)}	Nominal ID (B) 5.00 mm + 0.20 / - 0.00 _{(0.197 in.)}	Stock Thickness (C) 0.50 mm _{(0.02 in.)}		Loaded Height (L1) 0.56 mm	Load at L1 33.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 0.75 mm Actual ID (Ref): 5.2 mm Inside Height (D): 0.25 mm
Part Number: W0050-D-010-005-S4 (100 Pcs) Disc Spring Washers - 10x5x0.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $21.41 AUD Regular price ~~$25.69 AUD~~ Sale price $21.41 AUD Unit price per Per 100
Nominal OD (A) 10.00 mm _{(0.394 in.)}	Nominal ID (B) 5.00 mm + 0.20 / - 0.00 _{(0.197 in.)}	Stock Thickness (C) 0.50 mm _{(0.02 in.)}
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.56 mm Load at L1: 33.0 kg Free Height (E): 0.75 mm Actual ID (Ref): 5.2 mm Inside Height (D): 0.25 mm
Part Number: W0050-D-010-005-S4 (100 Pcs) Disc Spring Washers - 10x5x0.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $21.41 AUD Regular price ~~$25.69 AUD~~ Sale price $21.41 AUD Unit price per Per 100 View the product page first if you are unsure.
W0050-D-010-005-S4 (100 Pcs) --- Disc Spring Washers - 10x5x0.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0050-D-010-005-S4 (100 Pcs) --- Disc Spring Washers - 10x5x0.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $21.41 AUD Regular price ~~$25.69 AUD~~ Sale price $21.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 12.50 mm _{(0.492 in.)}	Nominal ID (B) 6.00 mm + 0.20 / - 0.00 _{(0.236 in.)}	Stock Thickness (C) 0.70 mm _{(0.028 in.)}		Loaded Height (L1) 0.22 mm	Load at L1 60.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 1.00 mm Actual ID (Ref): 6.2 mm Inside Height (D): 0.30 mm
Part Number: W0060-D-013-007-S4 (100 Pcs) Disc Spring Washers - 12.5x6x0.7 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $22.23 AUD Regular price ~~$26.67 AUD~~ Sale price $22.23 AUD Unit price per Per 100
Nominal OD (A) 12.50 mm _{(0.492 in.)}	Nominal ID (B) 6.00 mm + 0.20 / - 0.00 _{(0.236 in.)}	Stock Thickness (C) 0.70 mm _{(0.028 in.)}
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.22 mm Load at L1: 60.0 kg Free Height (E): 1.00 mm Actual ID (Ref): 6.2 mm Inside Height (D): 0.30 mm
Part Number: W0060-D-013-007-S4 (100 Pcs) Disc Spring Washers - 12.5x6x0.7 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $22.23 AUD Regular price ~~$26.67 AUD~~ Sale price $22.23 AUD Unit price per Per 100 View the product page first if you are unsure.
W0060-D-013-007-S4 (100 Pcs) --- Disc Spring Washers - 12.5x6x0.7 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0060-D-013-007-S4 (100 Pcs) --- Disc Spring Washers - 12.5x6x0.7 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $22.23 AUD Regular price ~~$26.67 AUD~~ Sale price $22.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 12.70 mm _{(0.5 in.)}	Nominal ID (B) 6.35 mm + 0.20 / - 0.00 _{(0.25 in.)}	Stock Thickness (C) 0.64 mm _{(0.025 in.)}	Load to flatten 71.43 kg	Loaded Height (L1) 0.79 mm	Load at L1 42.4 kg
Material: Stainless Steel 302/304 (Similar to A2, 18-8) Free Height (E): 0.97 mm Inside Height (D): 0.33 mm
Part Number: W0064-D-013-006-S2 Disc Spring Washers - 12.7x6.35x0.64 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 Out of Stock \| Backorder Now \| Orders can be expected around Sat, Aug 02, 2025 Regular price $3.50 AUD Regular price Sale price $3.50 AUD Unit price per Each
Nominal OD (A) 12.70 mm _{(0.5 in.)}	Nominal ID (B) 6.35 mm + 0.20 / - 0.00 _{(0.25 in.)}	Stock Thickness (C) 0.64 mm _{(0.025 in.)}	Load to flatten 71.43 kg
Material: Stainless Steel 302/304 (Similar to A2, 18-8) Loaded Height (L1): 0.79 mm Load at L1: 42.4 kg Free Height (E): 0.97 mm Inside Height (D): 0.33 mm
Part Number: W0064-D-013-006-S2 Disc Spring Washers - 12.7x6.35x0.64 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 Out of Stock \| Backorder Now \| Orders can be expected around Sat, Aug 02, 2025 Regular price $3.50 AUD Regular price Sale price $3.50 AUD Unit price per Each View the product page first if you are unsure.
W0064-D-013-006-S2 --- Disc Spring Washers - 12.7x6.35x0.64 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 W0064-D-013-006-S2 --- Disc Spring Washers - 12.7x6.35x0.64 mm Standard - Stainless Steel 302/304 Similar to A2, 18-8 Regular price $3.50 AUD Regular price Sale price $3.50 AUD Unit price per Out of stock! Backorder Now
Nominal OD (A) 15.00 mm _{(0.591 in.)}	Nominal ID (B) 5.00 mm + 0.20 / - 0.00 _{(0.197 in.)}	Stock Thickness (C) 0.40 mm _{(0.016 in.)}		Loaded Height (L1) 0.54 mm	Load at L1 18.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 0.95 mm Actual ID (Ref): 5.2 mm Inside Height (D): 0.55 mm
Part Number: W0050-D-015-004-S17 (2 Pcs) Disc Spring Washers - 15x5x0.4 mm Standard - Stainless Steel 17-7 PH 50 units (100 pcs) Available Now \| Further orders can be expected around Sat, Sep 06, 2025 Regular price $4.86 AUD Regular price Sale price $4.86 AUD Unit price per Per 2
Nominal OD (A) 15.00 mm _{(0.591 in.)}	Nominal ID (B) 5.00 mm + 0.20 / - 0.00 _{(0.197 in.)}	Stock Thickness (C) 0.40 mm _{(0.016 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.54 mm Load at L1: 18.0 kg Free Height (E): 0.95 mm Actual ID (Ref): 5.2 mm Inside Height (D): 0.55 mm
Part Number: W0050-D-015-004-S17 (2 Pcs) Disc Spring Washers - 15x5x0.4 mm Standard - Stainless Steel 17-7 PH 50 units (100 pcs) Available Now \| Further orders can be expected around Sat, Sep 06, 2025 Regular price $4.86 AUD Regular price Sale price $4.86 AUD Unit price per Per 2 View the product page first if you are unsure.
W0050-D-015-004-S17 (2 Pcs) --- Disc Spring Washers - 15x5x0.4 mm Standard - Stainless Steel 17-7 PH W0050-D-015-004-S17 (2 Pcs) --- Disc Spring Washers - 15x5x0.4 mm Standard - Stainless Steel 17-7 PH Regular price $4.86 AUD Regular price Sale price $4.86 AUD Unit price per 50 Available Now
Nominal OD (A) 15.00 mm _{(0.591 in.)}	Nominal ID (B) 8.00 mm + 0.20 / - 0.00 _{(0.315 in.)}	Stock Thickness (C) 0.70 mm _{(0.028 in.)}		Loaded Height (L1) 0.80 mm	Load at L1 67.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 1.10 mm Actual ID (Ref): 8.2 mm Inside Height (D): 0.40 mm
Part Number: W0080-D-015-007-S17 (100 Pcs) Disc Spring Washers - 15x8x0.7 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $107.05 AUD Regular price ~~$128.45 AUD~~ Sale price $107.05 AUD Unit price per Per 100
Nominal OD (A) 15.00 mm _{(0.591 in.)}	Nominal ID (B) 8.00 mm + 0.20 / - 0.00 _{(0.315 in.)}	Stock Thickness (C) 0.70 mm _{(0.028 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.80 mm Load at L1: 67.0 kg Free Height (E): 1.10 mm Actual ID (Ref): 8.2 mm Inside Height (D): 0.40 mm
Part Number: W0080-D-015-007-S17 (100 Pcs) Disc Spring Washers - 15x8x0.7 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $107.05 AUD Regular price ~~$128.45 AUD~~ Sale price $107.05 AUD Unit price per Per 100 View the product page first if you are unsure.
W0080-D-015-007-S17 (100 Pcs) --- Disc Spring Washers - 15x8x0.7 mm Standard - Stainless Steel 17-7 PH Sale W0080-D-015-007-S17 (100 Pcs) --- Disc Spring Washers - 15x8x0.7 mm Standard - Stainless Steel 17-7 PH Regular price $107.05 AUD Regular price ~~$128.45 AUD~~ Sale price $107.05 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 16.00 mm _{(0.63 in.)}	Nominal ID (B) 8.00 mm + 0.20 / - 0.00 _{(0.315 in.)}	Stock Thickness (C) 0.90 mm _{(0.035 in.)}	Load to flatten N/A kg	Loaded Height (L1) 0.26 mm	Load at L1 93.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 1.25 mm Actual ID (Ref): 8.2 mm Inside Height (D): 0.35 mm
Part Number: W0080-D-016-009-S4 (10 Pcs) Disc Spring Washers - 16x8x0.9 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $2.59 AUD Regular price ~~$3.11 AUD~~ Sale price $2.59 AUD Unit price per Per 10
Nominal OD (A) 16.00 mm _{(0.63 in.)}	Nominal ID (B) 8.00 mm + 0.20 / - 0.00 _{(0.315 in.)}	Stock Thickness (C) 0.90 mm _{(0.035 in.)}	Load to flatten N/A kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.26 mm Load at L1: 93.0 kg Free Height (E): 1.25 mm Actual ID (Ref): 8.2 mm Inside Height (D): 0.35 mm
Part Number: W0080-D-016-009-S4 (10 Pcs) Disc Spring Washers - 16x8x0.9 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $2.59 AUD Regular price ~~$3.11 AUD~~ Sale price $2.59 AUD Unit price per Per 10 View the product page first if you are unsure.
W0080-D-016-009-S4 (10 Pcs) --- Disc Spring Washers - 16x8x0.9 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0080-D-016-009-S4 (10 Pcs) --- Disc Spring Washers - 16x8x0.9 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $2.59 AUD Regular price ~~$3.11 AUD~~ Sale price $2.59 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 20.00 mm _{(0.787 in.)}	Nominal ID (B) 10.00 mm + 0.20 / - 0.00 _{(0.394 in.)}	Stock Thickness (C) 1.10 mm _{(0.043 in.)}	Load to flatten N/A kg	Loaded Height (L1) 0.34 mm	Load at L1 140.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 1.55 mm Actual ID (Ref): 10.2 mm Inside Height (D): 0.45 mm
Part Number: W0100-D-020-011-S4 (50 Pcs) Disc Spring Washers - 20x10x1.1 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $20.05 AUD Regular price ~~$24.05 AUD~~ Sale price $20.05 AUD Unit price per Per 50
Nominal OD (A) 20.00 mm _{(0.787 in.)}	Nominal ID (B) 10.00 mm + 0.20 / - 0.00 _{(0.394 in.)}	Stock Thickness (C) 1.10 mm _{(0.043 in.)}	Load to flatten N/A kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.34 mm Load at L1: 140.0 kg Free Height (E): 1.55 mm Actual ID (Ref): 10.2 mm Inside Height (D): 0.45 mm
Part Number: W0100-D-020-011-S4 (50 Pcs) Disc Spring Washers - 20x10x1.1 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $20.05 AUD Regular price ~~$24.05 AUD~~ Sale price $20.05 AUD Unit price per Per 50 View the product page first if you are unsure.
W0100-D-020-011-S4 (50 Pcs) --- Disc Spring Washers - 20x10x1.1 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0100-D-020-011-S4 (50 Pcs) --- Disc Spring Washers - 20x10x1.1 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $20.05 AUD Regular price ~~$24.05 AUD~~ Sale price $20.05 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 22.50 mm _{(0.886 in.)}	Nominal ID (B) 11.00 mm + 0.20 / - 0.00 _{(0.433 in.)}	Stock Thickness (C) 0.80 mm _{(0.031 in.)}		Loaded Height (L1) 0.96 mm	Load at L1 71.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 1.45 mm Actual ID (Ref): 11.2 mm Inside Height (D): 0.65 mm
Part Number: W0110-D-023-008-S17 (50 Pcs) Disc Spring Washers - 22.5x11x0.8 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $127.77 AUD Regular price ~~$153.33 AUD~~ Sale price $127.77 AUD Unit price per Per 50
Nominal OD (A) 22.50 mm _{(0.886 in.)}	Nominal ID (B) 11.00 mm + 0.20 / - 0.00 _{(0.433 in.)}	Stock Thickness (C) 0.80 mm _{(0.031 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.96 mm Load at L1: 71.0 kg Free Height (E): 1.45 mm Actual ID (Ref): 11.2 mm Inside Height (D): 0.65 mm
Part Number: W0110-D-023-008-S17 (50 Pcs) Disc Spring Washers - 22.5x11x0.8 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sat, Sep 06, 2025 Regular price $127.77 AUD Regular price ~~$153.33 AUD~~ Sale price $127.77 AUD Unit price per Per 50 View the product page first if you are unsure.
W0110-D-023-008-S17 (50 Pcs) --- Disc Spring Washers - 22.5x11x0.8 mm Standard - Stainless Steel 17-7 PH Sale W0110-D-023-008-S17 (50 Pcs) --- Disc Spring Washers - 22.5x11x0.8 mm Standard - Stainless Steel 17-7 PH Regular price $127.77 AUD Regular price ~~$153.33 AUD~~ Sale price $127.77 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 23.00 mm _{(0.906 in.)}	Nominal ID (B) 8.00 mm + 0.20 / - 0.00 _{(0.315 in.)}	Stock Thickness (C) 0.80 mm _{(0.031 in.)}		Loaded Height (L1) 0.99 mm	Load at L1 72.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 1.55 mm Actual ID (Ref): 8.2 mm Inside Height (D): 0.75 mm
Part Number: W0080-D-023-008-S17 (2 Pcs) Disc Spring Washers - 23x8x0.8 mm Standard - Stainless Steel 17-7 PH 6 units (12 pcs) Available Now \| Item Discontinued - Up to 6 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $3.04 AUD Regular price ~~$7.96 AUD~~ Sale price $3.04 AUD Unit price per Per 2
Nominal OD (A) 23.00 mm _{(0.906 in.)}	Nominal ID (B) 8.00 mm + 0.20 / - 0.00 _{(0.315 in.)}	Stock Thickness (C) 0.80 mm _{(0.031 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 0.99 mm Load at L1: 72.0 kg Free Height (E): 1.55 mm Actual ID (Ref): 8.2 mm Inside Height (D): 0.75 mm
Part Number: W0080-D-023-008-S17 (2 Pcs) Disc Spring Washers - 23x8x0.8 mm Standard - Stainless Steel 17-7 PH 6 units (12 pcs) Available Now \| Item Discontinued - Up to 6 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $3.04 AUD Regular price ~~$7.96 AUD~~ Sale price $3.04 AUD Unit price per Per 2
W0080-D-023-008-S17 (2 Pcs) --- Disc Spring Washers - 23x8x0.8 mm Standard - Stainless Steel 17-7 PH Sale W0080-D-023-008-S17 (2 Pcs) --- Disc Spring Washers - 23x8x0.8 mm Standard - Stainless Steel 17-7 PH Regular price $3.04 AUD Regular price ~~$7.96 AUD~~ Sale price $3.04 AUD Unit price per 6 Available Now Sale
Nominal OD (A) 23.00 mm _{(0.906 in.)}	Nominal ID (B) 10.00 mm + 0.20 / - 0.00 _{(0.394 in.)}	Stock Thickness (C) 1.00 mm _{(0.039 in.)}		Loaded Height (L1) 1.17 mm	Load at L1 132.0 kg
Material: Stainless Steel 17-7 PH Load at 0.75 Height: 146.7 Kg Free Height (E): 1.70 mm Actual ID (Ref): 10.2 mm Inside Height (D): 0.70 mm
Part Number: W0100-D-023-010-S17 Disc Spring Washers - 23x10x1 mm Standard - Stainless Steel 17-7 PH 3 Available Now \| Item Discontinued - Up to 3 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $3.00 AUD Regular price ~~$5.70 AUD~~ Sale price $3.00 AUD Unit price per Each
Nominal OD (A) 23.00 mm _{(0.906 in.)}	Nominal ID (B) 10.00 mm + 0.20 / - 0.00 _{(0.394 in.)}	Stock Thickness (C) 1.00 mm _{(0.039 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 1.17 mm Load at L1: 132.0 kg Load at 0.75 Height: 146.7 Kg Free Height (E): 1.70 mm Actual ID (Ref): 10.2 mm Inside Height (D): 0.70 mm
Part Number: W0100-D-023-010-S17 Disc Spring Washers - 23x10x1 mm Standard - Stainless Steel 17-7 PH 3 Available Now \| Item Discontinued - Up to 3 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $3.00 AUD Regular price ~~$5.70 AUD~~ Sale price $3.00 AUD Unit price per Each
W0100-D-023-010-S17 --- Disc Spring Washers - 23x10x1 mm Standard - Stainless Steel 17-7 PH Sale W0100-D-023-010-S17 --- Disc Spring Washers - 23x10x1 mm Standard - Stainless Steel 17-7 PH Regular price $3.00 AUD Regular price ~~$5.70 AUD~~ Sale price $3.00 AUD Unit price per 3 Available Now Sale
Nominal OD (A) 25.00 mm _{(0.984 in.)}	Nominal ID (B) 12.00 mm + 0.20 / - 0.00 _{(0.472 in.)}	Stock Thickness (C) 1.50 mm _{(0.059 in.)}		Loaded Height (L1) 0.41 mm	Load at L1 268.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 2.05 mm Actual ID (Ref): 12.2 mm Inside Height (D): 0.55 mm
Part Number: W0120-D-025-015-S4 (50 Pcs) Disc Spring Washers - 25x12x1.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $30.86 AUD Regular price ~~$37.04 AUD~~ Sale price $30.86 AUD Unit price per Per 50
Nominal OD (A) 25.00 mm _{(0.984 in.)}	Nominal ID (B) 12.00 mm + 0.20 / - 0.00 _{(0.472 in.)}	Stock Thickness (C) 1.50 mm _{(0.059 in.)}
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.41 mm Load at L1: 268.0 kg Free Height (E): 2.05 mm Actual ID (Ref): 12.2 mm Inside Height (D): 0.55 mm
Part Number: W0120-D-025-015-S4 (50 Pcs) Disc Spring Washers - 25x12x1.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $30.86 AUD Regular price ~~$37.04 AUD~~ Sale price $30.86 AUD Unit price per Per 50 View the product page first if you are unsure.
W0120-D-025-015-S4 (50 Pcs) --- Disc Spring Washers - 25x12x1.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0120-D-025-015-S4 (50 Pcs) --- Disc Spring Washers - 25x12x1.5 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $30.86 AUD Regular price ~~$37.04 AUD~~ Sale price $30.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 31.50 mm _{(1.24 in.)}	Nominal ID (B) 16.00 mm + 0.30 / - 0.00 _{(0.63 in.)}	Stock Thickness (C) 1.50 mm _{(0.059 in.)}		Loaded Height (L1) 1.73 mm	Load at L1 323.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 2.40 mm Actual ID (Ref): 16.3 mm Inside Height (D): 0.90 mm
Part Number: W0160-D-032-015-S17 Disc Spring Washers - 31.5x16x1.5 mm Standard - Stainless Steel 17-7 PH 50 Available Now \| Further orders can be expected around Sat, Sep 06, 2025 Regular price $3.50 AUD Regular price ~~$4.20 AUD~~ Sale price $3.50 AUD Unit price per Each
Nominal OD (A) 31.50 mm _{(1.24 in.)}	Nominal ID (B) 16.00 mm + 0.30 / - 0.00 _{(0.63 in.)}	Stock Thickness (C) 1.50 mm _{(0.059 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 1.73 mm Load at L1: 323.0 kg Free Height (E): 2.40 mm Actual ID (Ref): 16.3 mm Inside Height (D): 0.90 mm
Part Number: W0160-D-032-015-S17 Disc Spring Washers - 31.5x16x1.5 mm Standard - Stainless Steel 17-7 PH 50 Available Now \| Further orders can be expected around Sat, Sep 06, 2025 Regular price $3.50 AUD Regular price ~~$4.20 AUD~~ Sale price $3.50 AUD Unit price per Each View the product page first if you are unsure.
W0160-D-032-015-S17 --- Disc Spring Washers - 31.5x16x1.5 mm Standard - Stainless Steel 17-7 PH Sale W0160-D-032-015-S17 --- Disc Spring Washers - 31.5x16x1.5 mm Standard - Stainless Steel 17-7 PH Regular price $3.50 AUD Regular price ~~$4.20 AUD~~ Sale price $3.50 AUD Unit price per 50 Available Now Sale
Nominal OD (A) 31.50 mm _{(1.24 in.)}	Nominal ID (B) 16.00 mm + 0.30 / - 0.00 _{(0.63 in.)}	Stock Thickness (C) 1.75 mm _{(0.069 in.)}	Load to flatten N/A kg	Loaded Height (L1) 0.52 mm	Load at L1 356.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 2.45 mm Actual ID (Ref): 16.3 mm Inside Height (D): 0.70 mm
Part Number: W0160-D-032-018-S4 (100 Pcs) Disc Spring Washers - 31.5x16x1.75 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $98.86 AUD Regular price ~~$118.64 AUD~~ Sale price $98.86 AUD Unit price per Per 100
Nominal OD (A) 31.50 mm _{(1.24 in.)}	Nominal ID (B) 16.00 mm + 0.30 / - 0.00 _{(0.63 in.)}	Stock Thickness (C) 1.75 mm _{(0.069 in.)}	Load to flatten N/A kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.52 mm Load at L1: 356.0 kg Free Height (E): 2.45 mm Actual ID (Ref): 16.3 mm Inside Height (D): 0.70 mm
Part Number: W0160-D-032-018-S4 (100 Pcs) Disc Spring Washers - 31.5x16x1.75 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $98.86 AUD Regular price ~~$118.64 AUD~~ Sale price $98.86 AUD Unit price per Per 100 View the product page first if you are unsure.
W0160-D-032-018-S4 (100 Pcs) --- Disc Spring Washers - 31.5x16x1.75 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0160-D-032-018-S4 (100 Pcs) --- Disc Spring Washers - 31.5x16x1.75 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $98.86 AUD Regular price ~~$118.64 AUD~~ Sale price $98.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 40.00 mm _{(1.575 in.)}	Nominal ID (B) 20.00 mm + 0.40 / - 0.00 _{(0.787 in.)}	Stock Thickness (C) 2.25 mm _{(0.089 in.)}	Load to flatten N/A kg	Loaded Height (L1) 0.67 mm	Load at L1 597.0 kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Free Height (E): 3.15 mm Actual ID (Ref): 20.4 mm Inside Height (D): 0.90 mm
Part Number: W0200-D-040-023-S4 (100 Pcs) Disc Spring Washers - 40x20x2.25 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $225.68 AUD Regular price ~~$270.82 AUD~~ Sale price $225.68 AUD Unit price per Per 100
Nominal OD (A) 40.00 mm _{(1.575 in.)}	Nominal ID (B) 20.00 mm + 0.40 / - 0.00 _{(0.787 in.)}	Stock Thickness (C) 2.25 mm _{(0.089 in.)}	Load to flatten N/A kg
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Loaded Height (L1): 0.67 mm Load at L1: 597.0 kg Free Height (E): 3.15 mm Actual ID (Ref): 20.4 mm Inside Height (D): 0.90 mm
Part Number: W0200-D-040-023-S4 (100 Pcs) Disc Spring Washers - 40x20x2.25 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 08, 2025 Regular price $225.68 AUD Regular price ~~$270.82 AUD~~ Sale price $225.68 AUD Unit price per Per 100 View the product page first if you are unsure.
W0200-D-040-023-S4 (100 Pcs) --- Disc Spring Washers - 40x20x2.25 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Sale W0200-D-040-023-S4 (100 Pcs) --- Disc Spring Washers - 40x20x2.25 mm Standard - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $225.68 AUD Regular price ~~$270.82 AUD~~ Sale price $225.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 40.00 mm + 0.50 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}		Loaded Height (L1) 4.40 mm	Load at L1 2334.0 kg
Material: Stainless Steel 17-7 PH Free Height (E): 5.60 mm Actual ID (Ref): 40.5 mm Inside Height (D): 1.60 mm
Part Number: W0400-D-070-040-S17 (5 Pcs) Disc Spring Washers - 70x40x4 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 07, 2025 Regular price $63.77 AUD Regular price ~~$76.53 AUD~~ Sale price $63.77 AUD Unit price per Per 5
Nominal OD (A) 70.00 mm _{(2.756 in.)}	Nominal ID (B) 40.00 mm + 0.50 / - 0.00 _{(1.575 in.)}	Stock Thickness (C) 4.00 mm _{(0.157 in.)}
Material: Stainless Steel 17-7 PH Loaded Height (L1): 4.40 mm Load at L1: 2334.0 kg Free Height (E): 5.60 mm Actual ID (Ref): 40.5 mm Inside Height (D): 1.60 mm
Part Number: W0400-D-070-040-S17 (5 Pcs) Disc Spring Washers - 70x40x4 mm Standard - Stainless Steel 17-7 PH Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 07, 2025 Regular price $63.77 AUD Regular price ~~$76.53 AUD~~ Sale price $63.77 AUD Unit price per Per 5 View the product page first if you are unsure.
W0400-D-070-040-S17 (5 Pcs) --- Disc Spring Washers - 70x40x4 mm Standard - Stainless Steel 17-7 PH Sale W0400-D-070-040-S17 (5 Pcs) --- Disc Spring Washers - 70x40x4 mm Standard - Stainless Steel 17-7 PH Regular price $63.77 AUD Regular price ~~$76.53 AUD~~ Sale price $63.77 AUD Unit price per Out of stock! Backorder Now Sale
