Screws - Socket Cap - Alloy Steel - Black Oxide

177 Products in this selection
  • UNC - UNF - METRIC - Alloy Steel.
  • Imperial Sizes to ANSI B18.3.
  • Metric Sizes to DIN912.
Additional resources:
PDF Screws Catalogue
Washers
Nuts

A more comprehensive listing may be found on the MBA Minibearings main store at Screws - Socket Cap - Alloy Steel - Black Oxide.
Thread Size (C) Thread Length (L) Material Head Length (B Max.) Head Diameter (A Max.) Drive Depth (E) Indicative
M10 (10x1.5mm)
10
mm 		High Tensile Steel / Black Oxide
10.0
mm 		16.0
mm 		5.00
mm 		1091675 | SC100M-010-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 10 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 10 mm
Part Number: SC100M-010-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 10 mm - High Tensile Steel / Black Oxide
26 units (130 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$4.05 AUD
$4.05 AUD
Per 5
Thread Size (C) Thread Length (L) Material Head Length (B Max.) Indicative
M10 (10x1.5mm)
10
mm 		High Tensile Steel / Black Oxide
10.0
mm 		1091675 | SC100M-010-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 10 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 16.0 mm    Drive Depth (E): 5.00 mm    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 10 mm
Part Number: SC100M-010-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 10 mm - High Tensile Steel / Black Oxide
26 units (130 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$4.05 AUD
$4.05 AUD
Per 5
View the product page first if you are unsure.
M10 (10x1.5mm)
25
mm 		High Tensile Steel / Black Oxide
10.0
mm 		16.0
mm 		5.00
mm 		1093341 | SC100M-025-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 25 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 25 mm
Part Number: SC100M-025-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 25 mm - High Tensile Steel / Black Oxide
10 units (50 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$3.68 AUD
$3.68 AUD
Per 5
M10 (10x1.5mm)
25
mm 		High Tensile Steel / Black Oxide
10.0
mm 		1093341 | SC100M-025-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 25 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 16.0 mm    Drive Depth (E): 5.00 mm    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 25 mm
Part Number: SC100M-025-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 25 mm - High Tensile Steel / Black Oxide
10 units (50 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$3.68 AUD
$3.68 AUD
Per 5
View the product page first if you are unsure.
M10 (10x1.5mm)
35
mm 		High Tensile Steel / Black Oxide
10.0
mm 		16.0
mm 		5.00
mm 		1093904 | SC100M-035-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 35 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 32 mm
Part Number: SC100M-035-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 35 mm - High Tensile Steel / Black Oxide
19 units (95 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$4.05 AUD
$4.05 AUD
Per 5
M10 (10x1.5mm)
35
mm 		High Tensile Steel / Black Oxide
10.0
mm 		1093904 | SC100M-035-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 35 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 16.0 mm    Drive Depth (E): 5.00 mm    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 32 mm
Part Number: SC100M-035-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 35 mm - High Tensile Steel / Black Oxide
19 units (95 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$4.05 AUD
$4.05 AUD
Per 5
View the product page first if you are unsure.
M10 (10x1.5mm)
40
mm 		High Tensile Steel / Black Oxide
10.0
mm 		16.0
mm 		5.00
mm 		1094041 | SC100M-040-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 40 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 32 mm
Part Number: SC100M-040-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 40 mm - High Tensile Steel / Black Oxide
12 units (60 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$6.41 AUD
$6.41 AUD
Per 5
M10 (10x1.5mm)
40
mm 		High Tensile Steel / Black Oxide
10.0
mm 		1094041 | SC100M-040-C-SK-C (5 Pcs) --- Socket Cap Screws - M10 -10x1.5mm- 40 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 16.0 mm    Drive Depth (E): 5.00 mm    Shank Diameter (C): 9.78 - 10.00 mm    Hex Key (D): 8.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 32 mm
Part Number: SC100M-040-C-SK-C (5 Pcs) Socket Cap Screws - M10 -10x1.5mm- 40 mm - High Tensile Steel / Black Oxide
12 units (60 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$6.41 AUD
$6.41 AUD
Per 5
View the product page first if you are unsure.
M12x1.5 (Fine)
20
mm 		High Tensile Steel / Black Oxide
12.0
mm 		18.0
mm 		6.00
mm 		1097324 | SC120MF-020-C-SK-C (2 Pcs) --- Socket Cap Screws - M12x1.5 -Fine- 20 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 11.73 - 12.00 mm    Hex Key (D): 10.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 36 mm
Part Number: SC120MF-020-C-SK-C (2 Pcs) Socket Cap Screws - M12x1.5 -Fine- 20 mm - High Tensile Steel / Black Oxide
50 units (100 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$6.14 AUD
$6.14 AUD
Per 2
M12x1.5 (Fine)
20
mm 		High Tensile Steel / Black Oxide
12.0
mm 		1097324 | SC120MF-020-C-SK-C (2 Pcs) --- Socket Cap Screws - M12x1.5 -Fine- 20 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 18.0 mm    Drive Depth (E): 6.00 mm    Shank Diameter (C): 11.73 - 12.00 mm    Hex Key (D): 10.00 mm    Pitch: 1.500 mm    Threads Per Inch: 16.93 TPI    Min thread Length: 36 mm
Part Number: SC120MF-020-C-SK-C (2 Pcs) Socket Cap Screws - M12x1.5 -Fine- 20 mm - High Tensile Steel / Black Oxide
50 units (100 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$6.14 AUD
$6.14 AUD
Per 2
View the product page first if you are unsure.
M12 (12x1.75mm)
40
mm 		High Tensile Steel / Black Oxide
12.0
mm 		18.0
mm 		6.00
mm 		1100304 | SC120M-040-C-SK-C (10 Pcs) --- Socket Cap Screws - M12 -12x1.75mm- 40 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 11.73 - 12.00 mm    Hex Key (D): 10.00 mm    Pitch: 1.750 mm    Threads Per Inch: 14.51 TPI    Min thread Length: 36 mm
Part Number: SC120M-040-C-SK-C (10 Pcs) Socket Cap Screws - M12 -12x1.75mm- 40 mm - High Tensile Steel / Black Oxide
5 units (50 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$16.68 AUD
$16.68 AUD
Per 10
M12 (12x1.75mm)
40
mm 		High Tensile Steel / Black Oxide
12.0
mm 		1100304 | SC120M-040-C-SK-C (10 Pcs) --- Socket Cap Screws - M12 -12x1.75mm- 40 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 18.0 mm    Drive Depth (E): 6.00 mm    Shank Diameter (C): 11.73 - 12.00 mm    Hex Key (D): 10.00 mm    Pitch: 1.750 mm    Threads Per Inch: 14.51 TPI    Min thread Length: 36 mm
Part Number: SC120M-040-C-SK-C (10 Pcs) Socket Cap Screws - M12 -12x1.75mm- 40 mm - High Tensile Steel / Black Oxide
5 units (50 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$16.68 AUD
$16.68 AUD
Per 10
View the product page first if you are unsure.
1/2-13 UNC (12.7mm)
19.1
mm 		High Tensile Steel / Black Oxide
12.7
mm 		19.1
mm 		6.22
mm 		1103349 | SC127C-019-C-SK-C (5 Pcs) --- Socket Cap Screws - 1/2-13 UNC -12.7mm- 19.1 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 12.49 - 12.74 mm    Hex Key (D): 9.53 (3/8) mm    Pitch: 1.954 mm    Threads Per Inch: 13 TPI    Min thread Length: 19.1 mm
Part Number: SC127C-019-C-SK-C (5 Pcs) Socket Cap Screws - 1/2-13 UNC -12.7mm- 19.1 mm - High Tensile Steel / Black Oxide
10 units (50 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$7.77 AUD
$7.77 AUD
Per 5
1/2-13 UNC (12.7mm)
19.1
mm 		High Tensile Steel / Black Oxide
12.7
mm 		1103349 | SC127C-019-C-SK-C (5 Pcs) --- Socket Cap Screws - 1/2-13 UNC -12.7mm- 19.1 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 19.1 mm    Drive Depth (E): 6.22 mm    Shank Diameter (C): 12.49 - 12.74 mm    Hex Key (D): 9.53 (3/8) mm    Pitch: 1.954 mm    Threads Per Inch: 13 TPI    Min thread Length: 19.1 mm
Part Number: SC127C-019-C-SK-C (5 Pcs) Socket Cap Screws - 1/2-13 UNC -12.7mm- 19.1 mm - High Tensile Steel / Black Oxide
10 units (50 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$7.77 AUD
$7.77 AUD
Per 5
View the product page first if you are unsure.
1/2-13 UNC (12.7mm)
76.2
mm 		High Tensile Steel / Black Oxide
12.7
mm 		19.1
mm 		6.22
mm 		1104699 | SC127C-076-C-SK-C (2 Pcs) --- Socket Cap Screws - 1/2-13 UNC -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 12.49 - 12.74 mm    Hex Key (D): 9.53 (3/8) mm    Pitch: 1.954 mm    Threads Per Inch: 13 TPI    Min thread Length: 38.1 mm
Part Number: SC127C-076-C-SK-C (2 Pcs) Socket Cap Screws - 1/2-13 UNC -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
22 units (44 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$8.68 AUD
$8.68 AUD
Per 2
1/2-13 UNC (12.7mm)
76.2
mm 		High Tensile Steel / Black Oxide
12.7
mm 		1104699 | SC127C-076-C-SK-C (2 Pcs) --- Socket Cap Screws - 1/2-13 UNC -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 19.1 mm    Drive Depth (E): 6.22 mm    Shank Diameter (C): 12.49 - 12.74 mm    Hex Key (D): 9.53 (3/8) mm    Pitch: 1.954 mm    Threads Per Inch: 13 TPI    Min thread Length: 38.1 mm
Part Number: SC127C-076-C-SK-C (2 Pcs) Socket Cap Screws - 1/2-13 UNC -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
22 units (44 pcs) Available Now | Further orders can be expected around Tue, Jun 17, 2025
$8.68 AUD
$8.68 AUD
Per 2
View the product page first if you are unsure.
1/2-20 UNF (12.7mm)
76.2
mm 		High Tensile Steel / Black Oxide
12.7
mm 		19.1
mm 		6.22
mm 		1105543 | SC127F-076-C-SK-C (10 Pcs) --- Socket Cap Screws - 1/2-20 UNF -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Shank Diameter (C): 12.49 - 12.74 mm    Hex Key (D): 9.53 (3/8) mm    Pitch: 1.270 mm    Threads Per Inch: 20 TPI    Min thread Length: 38.1 mm
Part Number: SC127F-076-C-SK-C (10 Pcs) Socket Cap Screws - 1/2-20 UNF -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
5 units (50 pcs) Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$10.76 AUD
$29.64 AUD $10.76 AUD
Per 10
1/2-20 UNF (12.7mm)
76.2
mm 		High Tensile Steel / Black Oxide
12.7
mm 		1105543 | SC127F-076-C-SK-C (10 Pcs) --- Socket Cap Screws - 1/2-20 UNF -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
Material: High Tensile Steel Black Oxide    Head Diameter (A Max.): 19.1 mm    Drive Depth (E): 6.22 mm    Shank Diameter (C): 12.49 - 12.74 mm    Hex Key (D): 9.53 (3/8) mm    Pitch: 1.270 mm    Threads Per Inch: 20 TPI    Min thread Length: 38.1 mm
Part Number: SC127F-076-C-SK-C (10 Pcs) Socket Cap Screws - 1/2-20 UNF -12.7mm- 76.2 mm - High Tensile Steel / Black Oxide
5 units (50 pcs) Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$10.76 AUD
$29.64 AUD $10.76 AUD
Per 10
