Rod Ends - Male - Steel

13 Products in this selection
This is a combined category of Steel Male Rod Ends.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.
Additional resources:

A more comprehensive listing may be found on the MBA Minibearings main store at Rod Ends - Male - Steel.
Eye Size (d1) Overall Length (L) Thread Size Min. Thread Length (l2) Head Width (W) Eye Width (W1) Indicative
3
mm 		33.00
mm 		M3x0.5 Left
15.00
mm 		4.30
mm 		6.00
mm 		1047916 | REM-030-L-CB --- Male Rod Ends - 3x33 mm - M3x0.5 Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 12.00 mm    Centre Height: 27.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-030-L-CB Male Rod Ends - 3x33 mm - M3x0.5 Left - Bronze Lined Steel
8 Available Now | Further orders can be expected around Wed, May 14, 2025
$8.05 AUD
$9.65 AUD $8.05 AUD
Each
Eye Size (d1) Overall Length (L) Thread Size Min. Thread Length (l2) Indicative
3
mm 		33.00
mm 		M3x0.5 Left
15.00
mm 		1047916 | REM-030-L-CB --- Male Rod Ends - 3x33 mm - M3x0.5 Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 4.30 mm    Eye Width (W1): 6.00 mm    Head Diameter: 12.00 mm    Centre Height: 27.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-030-L-CB Male Rod Ends - 3x33 mm - M3x0.5 Left - Bronze Lined Steel
8 Available Now | Further orders can be expected around Wed, May 14, 2025
$8.05 AUD
$9.65 AUD $8.05 AUD
Each
View the product page first if you are unsure.
3
mm 		33.00
mm 		M3x0.5 Right
15.00
mm 		4.50
mm 		6.00
mm 		1047917 | REM-030-R-CB --- Male Rod Ends - 3x33 mm - M3x0.5 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 12.00 mm    Centre Height: 27.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-030-R-CB Male Rod Ends - 3x33 mm - M3x0.5 Right - Bronze Lined Steel
30 Available Now | Further orders can be expected around Wed, May 14, 2025
$10.41 AUD
$10.41 AUD
Each
3
mm 		33.00
mm 		M3x0.5 Right
15.00
mm 		1047917 | REM-030-R-CB --- Male Rod Ends - 3x33 mm - M3x0.5 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 4.50 mm    Eye Width (W1): 6.00 mm    Head Diameter: 12.00 mm    Centre Height: 27.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-030-R-CB Male Rod Ends - 3x33 mm - M3x0.5 Right - Bronze Lined Steel
30 Available Now | Further orders can be expected around Wed, May 14, 2025
$10.41 AUD
$10.41 AUD
Each
View the product page first if you are unsure.
4
mm 		37.00
mm 		M4x0.7 Right
17.00
mm 		5.30
mm 		7.00
mm 		1055799 | REM-040-R-CB --- Male Rod Ends - 4x37 mm - M4x0.7 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 14.00 mm    Centre Height: 30.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-040-R-CB Male Rod Ends - 4x37 mm - M4x0.7 Right - Bronze Lined Steel
30 Available Now | Further orders can be expected around Wed, May 14, 2025
$7.50 AUD
$9.00 AUD $7.50 AUD
Each
4
mm 		37.00
mm 		M4x0.7 Right
17.00
mm 		1055799 | REM-040-R-CB --- Male Rod Ends - 4x37 mm - M4x0.7 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 5.30 mm    Eye Width (W1): 7.00 mm    Head Diameter: 14.00 mm    Centre Height: 30.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-040-R-CB Male Rod Ends - 4x37 mm - M4x0.7 Right - Bronze Lined Steel
30 Available Now | Further orders can be expected around Wed, May 14, 2025
$7.50 AUD
$9.00 AUD $7.50 AUD
Each
View the product page first if you are unsure.
4.763
mm 		39.70
mm 		10-32 UNF Left
19.05
mm 		6.35
mm 		7.92
mm 		1060606 | REM-048-L-CB --- Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 15.88 mm    Centre Height: 31.75 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-048-L-CB Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Left - Bronze Lined Steel
50 Available Now | Further orders can be expected around Wed, May 14, 2025
$9.23 AUD
$11.07 AUD $9.23 AUD
Each
4.763
mm 		39.70
mm 		10-32 UNF Left
19.05
mm 		1060606 | REM-048-L-CB --- Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 6.35 mm    Eye Width (W1): 7.92 mm    Head Diameter: 15.88 mm    Centre Height: 31.75 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-048-L-CB Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Left - Bronze Lined Steel
50 Available Now | Further orders can be expected around Wed, May 14, 2025
$9.23 AUD
$11.07 AUD $9.23 AUD
Each
View the product page first if you are unsure.
4.763
mm 		39.70
mm 		10-32 UNF Right
19.05
mm 		6.35
mm 		7.92
mm 		1060608 | REM-048-R-CB --- Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 15.88 mm    Centre Height: 31.75 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-048-R-CB Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Right - Bronze Lined Steel
14 Available Now | Further orders can be expected around Wed, May 14, 2025
$8.59 AUD
$8.59 AUD
Each
4.763
mm 		39.70
mm 		10-32 UNF Right
19.05
mm 		1060608 | REM-048-R-CB --- Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 6.35 mm    Eye Width (W1): 7.92 mm    Head Diameter: 15.88 mm    Centre Height: 31.75 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-048-R-CB Male Rod Ends - 4.763x39.7 mm - 10-32 UNF Right - Bronze Lined Steel
14 Available Now | Further orders can be expected around Wed, May 14, 2025
$8.59 AUD
$8.59 AUD
Each
View the product page first if you are unsure.
5
mm 		41.00
mm 		M5x0.8 Right
20.00
mm 		6.00
mm 		8.00
mm 		1064954 | REM-050-R-CB --- Male Rod Ends - 5x41 mm - M5x0.8 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 16.00 mm    Centre Height: 33.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-050-R-CB Male Rod Ends - 5x41 mm - M5x0.8 Right - Bronze Lined Steel
30 Available Now | Further orders can be expected around Wed, May 14, 2025
$9.32 AUD
$9.32 AUD
Each
5
mm 		41.00
mm 		M5x0.8 Right
20.00
mm 		1064954 | REM-050-R-CB --- Male Rod Ends - 5x41 mm - M5x0.8 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 6.00 mm    Eye Width (W1): 8.00 mm    Head Diameter: 16.00 mm    Centre Height: 33.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-050-R-CB Male Rod Ends - 5x41 mm - M5x0.8 Right - Bronze Lined Steel
30 Available Now | Further orders can be expected around Wed, May 14, 2025
$9.32 AUD
$9.32 AUD
Each
View the product page first if you are unsure.
6.35
mm 		49.20
mm 		1/4-28 UNF Right
25.40
mm 		7.14
mm 		9.53
mm 		1074950 | REM-064-R-CB --- Male Rod Ends - 6.35x49.2 mm - 1/4-28 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 19.05 mm    Centre Height: 39.67 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-064-R-CB Male Rod Ends - 6.35x49.2 mm - 1/4-28 UNF Right - Bronze Lined Steel
6 Available Now | Further orders can be expected around Wed, May 14, 2025
$5.95 AUD
$5.95 AUD
Each
6.35
mm 		49.20
mm 		1/4-28 UNF Right
25.40
mm 		1074950 | REM-064-R-CB --- Male Rod Ends - 6.35x49.2 mm - 1/4-28 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 7.14 mm    Eye Width (W1): 9.53 mm    Head Diameter: 19.05 mm    Centre Height: 39.67 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-064-R-CB Male Rod Ends - 6.35x49.2 mm - 1/4-28 UNF Right - Bronze Lined Steel
6 Available Now | Further orders can be expected around Wed, May 14, 2025
$5.95 AUD
$5.95 AUD
Each
View the product page first if you are unsure.
7.938
mm 		58.72
mm 		5/16-24 UNF Right
31.75
mm 		8.74
mm 		11.10
mm 		1079382 | REM-079-R-CB --- Male Rod Ends - 7.938x58.72 mm - 5/16-24 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 22.23 mm    Centre Height: 47.63 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-079-R-CB Male Rod Ends - 7.938x58.72 mm - 5/16-24 UNF Right - Bronze Lined Steel
8 Available Now | Further orders can be expected around Wed, May 14, 2025
$5.95 AUD
$5.95 AUD
Each
7.938
mm 		58.72
mm 		5/16-24 UNF Right
31.75
mm 		1079382 | REM-079-R-CB --- Male Rod Ends - 7.938x58.72 mm - 5/16-24 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 8.74 mm    Eye Width (W1): 11.10 mm    Head Diameter: 22.23 mm    Centre Height: 47.63 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-079-R-CB Male Rod Ends - 7.938x58.72 mm - 5/16-24 UNF Right - Bronze Lined Steel
8 Available Now | Further orders can be expected around Wed, May 14, 2025
$5.95 AUD
$5.95 AUD
Each
View the product page first if you are unsure.
8
mm 		53.00
mm 		M8x1.25 Left
25.00
mm 		9.00
mm 		12.00
mm 		1084102 | REM-080-L-CB --- Male Rod Ends - 8x53 mm - M8x1.25 Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 22.00 mm    Centre Height: 42.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-080-L-CB Male Rod Ends - 8x53 mm - M8x1.25 Left - Bronze Lined Steel
1 Available Now | Further orders can be expected around Fri, May 23, 2025
$8.95 AUD
$8.95 AUD
Each
8
mm 		53.00
mm 		M8x1.25 Left
25.00
mm 		1084102 | REM-080-L-CB --- Male Rod Ends - 8x53 mm - M8x1.25 Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 9.00 mm    Eye Width (W1): 12.00 mm    Head Diameter: 22.00 mm    Centre Height: 42.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-080-L-CB Male Rod Ends - 8x53 mm - M8x1.25 Left - Bronze Lined Steel
1 Available Now | Further orders can be expected around Fri, May 23, 2025
$8.95 AUD
$8.95 AUD
Each
View the product page first if you are unsure.
8
mm 		53.00
mm 		M8x1.25 Right
25.00
mm 		9.00
mm 		12.00
mm 		1084103 | REM-080-R-CB --- Male Rod Ends - 8x53 mm - M8x1.25 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 22.00 mm    Centre Height: 42.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-080-R-CB Male Rod Ends - 8x53 mm - M8x1.25 Right - Bronze Lined Steel
6 Available Now | Further orders can be expected around Wed, May 14, 2025
$7.32 AUD
$8.78 AUD $7.32 AUD
Each
8
mm 		53.00
mm 		M8x1.25 Right
25.00
mm 		1084103 | REM-080-R-CB --- Male Rod Ends - 8x53 mm - M8x1.25 Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 9.00 mm    Eye Width (W1): 12.00 mm    Head Diameter: 22.00 mm    Centre Height: 42.00 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-080-R-CB Male Rod Ends - 8x53 mm - M8x1.25 Right - Bronze Lined Steel
6 Available Now | Further orders can be expected around Wed, May 14, 2025
$7.32 AUD
$8.78 AUD $7.32 AUD
Each
View the product page first if you are unsure.
9.525
mm 		61.93
mm 		3/8-24 UNF Left
31.75
mm 		10.31
mm 		12.70
mm 		1088819 | REM-095-L-CB --- Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 25.40 mm    Centre Height: 49.23 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-095-L-CB Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Left - Bronze Lined Steel
10 Available Now | Further orders can be expected around Wed, May 14, 2025
$10.86 AUD
$13.04 AUD $10.86 AUD
Each
9.525
mm 		61.93
mm 		3/8-24 UNF Left
31.75
mm 		1088819 | REM-095-L-CB --- Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Left - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 10.31 mm    Eye Width (W1): 12.70 mm    Head Diameter: 25.40 mm    Centre Height: 49.23 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-095-L-CB Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Left - Bronze Lined Steel
10 Available Now | Further orders can be expected around Wed, May 14, 2025
$10.86 AUD
$13.04 AUD $10.86 AUD
Each
View the product page first if you are unsure.
9.525
mm 		61.93
mm 		3/8-24 UNF Right
31.75
mm 		10.31
mm 		12.70
mm 		1088821 | REM-095-R-CB --- Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 25.40 mm    Centre Height: 49.23 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-095-R-CB Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Right - Bronze Lined Steel
8 Available Now | Further orders can be expected around Wed, May 14, 2025
$10.86 AUD
$13.04 AUD $10.86 AUD
Each
9.525
mm 		61.93
mm 		3/8-24 UNF Right
31.75
mm 		1088821 | REM-095-R-CB --- Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 10.31 mm    Eye Width (W1): 12.70 mm    Head Diameter: 25.40 mm    Centre Height: 49.23 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-095-R-CB Male Rod Ends - 9.525x61.93 mm - 3/8-24 UNF Right - Bronze Lined Steel
8 Available Now | Further orders can be expected around Wed, May 14, 2025
$10.86 AUD
$13.04 AUD $10.86 AUD
Each
View the product page first if you are unsure.
19.05
mm 		95.25
mm 		3/4-16 UNF Right
44.45
mm 		17.45
mm 		22.23
mm 		1122259 | REM-191-R-CB --- Male Rod Ends - 19.05x95.25 mm - 3/4-16 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Diameter: 44.45 mm    Centre Height: 73.03 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-191-R-CB Male Rod Ends - 19.05x95.25 mm - 3/4-16 UNF Right - Bronze Lined Steel
1 Available Now | Further orders can be expected around Sun, Apr 27, 2025
$87.68 AUD
$87.68 AUD
Each
19.05
mm 		95.25
mm 		3/4-16 UNF Right
44.45
mm 		1122259 | REM-191-R-CB --- Male Rod Ends - 19.05x95.25 mm - 3/4-16 UNF Right - Bronze Lined Steel
Material: Bronze Lined Steel    Head Width (W): 17.45 mm    Eye Width (W1): 22.23 mm    Head Diameter: 44.45 mm    Centre Height: 73.03 mm
Category: Rod Ends - Male - Steel - Bronze Lined
Part Number: REM-191-R-CB Male Rod Ends - 19.05x95.25 mm - 3/4-16 UNF Right - Bronze Lined Steel
1 Available Now | Further orders can be expected around Sun, Apr 27, 2025
$87.68 AUD
$87.68 AUD
Each
View the product page first if you are unsure.
