Retaining Rings - Internal - Spiral Rings

Retaining Rings -> Internal -> Spiral Rings
Housing Bore (B) Clip Thickness (T) Groove Dia. (Dg) Approx. Loose Circlip OD (Dr) Radial Wall (S) Approx. Groove Width (W) Indicative
Internal Retaining Rings - 84.12x1.55x86.77 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Housing Bore (B)
84.12
mm
Clip Thickness (T)
1.55
mm
+/- 0.08
(Equiv. 0.061 in.)
Groove Dia. (Dg)
86.77
mm
Approx. Loose Circlip OD (Dr)
87.82
mm
+ 0.76 / - 0.00
Radial Wall (S) Approx.
4.78
mm
+/- 0.13
Groove Width (W)
1.79
mm
+/- 0.16
Internal Retaining Rings - 84.12x1.55x86.77 mm - Spring Steel
Material: Carbon Spring Steel    Approx. Loose Clip ID: 78.26 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Deleted Item. Available while stocks last.
Part Number: RR-331 (Each)
785 Available Now | Further orders can be expected around Mon, Apr 30, 2029
$9.00 AUD
$9.00 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Larger quantities than the 785 available can be backordered.
Housing Bore (B) Clip Thickness (T) Groove Dia. (Dg) Approx. Loose Circlip OD (Dr) Indicative
Internal Retaining Rings - 84.12x1.55x86.77 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Housing Bore (B)
84.12
mm
Clip Thickness (T)
1.55
mm
+/- 0.08
(Equiv. 0.061 in.)
Groove Dia. (Dg)
86.77
mm
Approx. Loose Circlip OD (Dr)
87.82
mm
+ 0.76 / - 0.00
Internal Retaining Rings - 84.12x1.55x86.77 mm - Spring Steel
Material: Carbon Spring Steel    Radial Wall (S) Approx.: 4.78 mm +/- 0.13    Groove Width (W): 1.79 mm +/- 0.16   Approx. Loose Clip ID: 78.26 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Deleted Item. Available while stocks last.
Part Number: RR-331 (Each)
785 Available Now | Further orders can be expected around Mon, Apr 30, 2029
$9.00 AUD
$9.00 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

785 Available Now. Backorder if more than 785.
Internal Retaining Rings - 107.95x1.55x111.25 mm Spiral Rings - Carbon Spring Steel
Housing Bore (B)
107.95
mm
Clip Thickness (T)
1.55
mm
+/- 0.08
(Equiv. 0.061 in.)
Groove Dia. (Dg)
111.25
mm
Approx. Loose Circlip OD (Dr)
112.70
mm
+ 0.89 / - 0.00
Radial Wall (S) Approx.
5.79
mm
+/- 0.13
Groove Width (W)
1.79
mm
+/- 0.15
1199126 | RR-425 (Each) --- Internal Retaining Rings - 107.95x1.55x111.25 mm Spiral Rings - Carbon Spring Steel
Material: Carbon Spring Steel    Approx. Loose Clip ID: 101.12 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Additional stock available from USA subject to Prior Sale = 55
Part Number: RR-425 (Each)
6 Available Now | Further orders can be expected around Wed, Sep 02, 2026
$23.05 AUD
$23.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Larger quantities than the 6 available can be backordered.
Internal Retaining Rings - 107.95x1.55x111.25 mm Spiral Rings - Carbon Spring Steel
Housing Bore (B)
107.95
mm
Clip Thickness (T)
1.55
mm
+/- 0.08
(Equiv. 0.061 in.)
Groove Dia. (Dg)
111.25
mm
Approx. Loose Circlip OD (Dr)
112.70
mm
+ 0.89 / - 0.00
1199126 | RR-425 (Each) --- Internal Retaining Rings - 107.95x1.55x111.25 mm Spiral Rings - Carbon Spring Steel
Material: Carbon Spring Steel    Radial Wall (S) Approx.: 5.79 mm +/- 0.13    Groove Width (W): 1.79 mm +/- 0.15   Approx. Loose Clip ID: 101.12 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Additional stock available from USA subject to Prior Sale = 55
Part Number: RR-425 (Each)
6 Available Now | Further orders can be expected around Wed, Sep 02, 2026
$23.05 AUD
$23.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

6 Available Now. Backorder if more than 6.
Internal Retaining Rings - 120.65x1.83x124.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Housing Bore (B)
120.65
mm
Clip Thickness (T)
1.83
mm
+/- 0.08
(Equiv. 0.072 in.)
Groove Dia. (Dg)
124.21
mm
Approx. Loose Circlip OD (Dr)
125.96
mm
+ 0.89 / - 0.00
Radial Wall (S) Approx.
6.35
mm
+/- 0.13
Groove Width (W)
2.01
mm
+/- 0.16
1203417 | RR-475 (Each) --- Internal Retaining Rings - 120.65x1.83x124.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Material: Carbon Spring Steel    Approx. Loose Clip ID: 113.26 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Part Number: RR-475 (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Sat, Sep 19, 2026
$24.50 AUD
$29.40 AUD $24.50 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Internal Retaining Rings - 120.65x1.83x124.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Housing Bore (B)
120.65
mm
Clip Thickness (T)
1.83
mm
+/- 0.08
(Equiv. 0.072 in.)
Groove Dia. (Dg)
124.21
mm
Approx. Loose Circlip OD (Dr)
125.96
mm
+ 0.89 / - 0.00
1203417 | RR-475 (Each) --- Internal Retaining Rings - 120.65x1.83x124.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Material: Carbon Spring Steel    Radial Wall (S) Approx.: 6.35 mm +/- 0.13    Groove Width (W): 2.01 mm +/- 0.16   Approx. Loose Clip ID: 113.26 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Part Number: RR-475 (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Sat, Sep 19, 2026
$24.50 AUD
$29.40 AUD $24.50 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Internal Retaining Rings - 127x1.83x130.66 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Housing Bore (B)
127.00
mm
Clip Thickness (T)
1.83
mm
+/- 0.10
(Equiv. 0.072 in.)
Groove Dia. (Dg)
130.66
mm
Approx. Loose Circlip OD (Dr)
132.59
mm
+ 0.89 / - 0.00
Radial Wall (S) Approx.
6.35
mm
+/- 0.13
Groove Width (W)
2.07
mm
+/- 0.15
Material: Carbon Spring Steel    Approx. Loose Clip ID: 119.89 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Additional stock available from USA subject to Prior Sale = 21
Part Number: RR-500 (Each)
10 Available Now | Further orders can be expected around Wed, Sep 02, 2026
$22.77 AUD
$22.77 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Larger quantities than the 10 available can be backordered.
Internal Retaining Rings - 127x1.83x130.66 mm Spiral Rings - Carbon Spring Steel Spiral Ring
Housing Bore (B)
127.00
mm
Clip Thickness (T)
1.83
mm
+/- 0.10
(Equiv. 0.072 in.)
Groove Dia. (Dg)
130.66
mm
Approx. Loose Circlip OD (Dr)
132.59
mm
+ 0.89 / - 0.00
Material: Carbon Spring Steel    Radial Wall (S) Approx.: 6.35 mm +/- 0.13    Groove Width (W): 2.07 mm +/- 0.15   Approx. Loose Clip ID: 119.89 +/- 0.06
Category: Retaining Rings - Internal - Spiral Rings - Medium Duty
Additional stock available from USA subject to Prior Sale = 21
Part Number: RR-500 (Each)
10 Available Now | Further orders can be expected around Wed, Sep 02, 2026
$22.77 AUD
$22.77 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

10 Available Now. Backorder if more than 10.
