Includes series CI / VH / UR - Spring Steel
Light duty rings for use in low clearance applications.
Also used as a positioning point for light loads.
Radius notch on one end for removal.
Narrow radial wall yields moderate thrust loads.
Equivalent to Associated Spring: CI, Smalley: VH, Spirolox and Ramsey: UR

Additional resources:
Snap Rings
Spiral Rings and Snap Rings PDF

Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Radial Wall (S)	Groove Width (W)
15.88 mm	0.46 mm +/-0.04	16.59 mm	16.64 mm +0.33/-0.00	1.14 mm +0.08/-0.13	0.56 mm +/-0.05
Material: Spring Steel Approx. Loose Clip ID: 14.36 +0.05/-0.00 Groove Depth (d): 0.36
Part Number: UR-062 (13 Pcs) Spiral - 15.88 mm x 0.46 mm x 16.59 mm / Retaining Rings Out of Stock Backorder Now \| Backorders for more can be expected around Fri, Jan 17, 2025 Regular price $12.59 AUD Regular price Sale price $12.59 AUD Unit price per Per 13 View the product page first if you are unsure.
Housing Bore (B)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip OD (Dr)	Indicative Image
15.88 mm	0.46 mm +/-0.04	16.59 mm	16.64 mm +0.33/-0.00
Material: Spring Steel Radial Wall (S): 1.14 mm +0.08/-0.13 Groove Width (W): 0.56 mm +/-0.05 Approx. Loose Clip ID: 14.36 +0.05/-0.00 Groove Depth (d): 0.36
