Collection: Pulleys - Metric Timing - 3.000mm Pitch - HTD

Pulleys (With Images)

Metric Timing

3.000mm Pitch

22 Products in this selection

This is a combined category of HTD 3.000mm Pitch Metric Timing Pulleys.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
Timing Pulleys Catalogue PDF
3mm HTD Timing Belts

A more comprehensive listing may be found on the MBA Minibearings main store at Pulleys - Metric Timing - 3.000mm Pitch - HTD.

Teeth	Max Belt Width	Bore (d)	Bore Type	Locking Type
10	6.00 mm	3.000 mm	Finished	Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-010-060FH-AL-G-030 Metric Timing Pulleys - 10 tooth - 6x3 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $43.32 AUD Regular price Sale price $43.32 AUD Unit price per Each
Teeth	Max Belt Width	Bore (d)	Bore Type	Indicative Image
10	6.00 mm	3.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-010-060FH-AL-G-030 Metric Timing Pulleys - 10 tooth - 6x3 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $43.32 AUD Regular price Sale price $43.32 AUD Unit price per Each View the product page first if you are unsure.
P-030H-010-060FH-AL-G-030 --- Metric Timing Pulleys - 10 tooth - 6x3 mm - Aluminium P-030H-010-060FH-AL-G-030 --- Metric Timing Pulleys - 10 tooth - 6x3 mm - Aluminium Regular price $43.32 AUD Regular price Sale price $43.32 AUD Unit price per 2 Available Now
12	6.00 mm	4.000 mm	Finished	Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 11.45 mm Flange Diameter (FD): 14.7 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-012-060FH-AL-G-040 Metric Timing Pulleys - 12 tooth - 6x4 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Each
12	6.00 mm	4.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 11.45 mm Flange Diameter (FD): 14.7 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-012-060FH-AL-G-040 Metric Timing Pulleys - 12 tooth - 6x4 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Each View the product page first if you are unsure.
P-030H-012-060FH-AL-G-040 --- Metric Timing Pulleys - 12 tooth - 6x4 mm - Aluminium P-030H-012-060FH-AL-G-040 --- Metric Timing Pulleys - 12 tooth - 6x4 mm - Aluminium Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per 2 Available Now
12	100.0 mm	11.50 mm	10.70
Material: Aluminium Pitch Dia. (PD): 6.30 mm Flange Diameter (FD): 22.0 mm Category: Pulleys - Metric Timing Stock - 3.000mm Pitch - HTD - Aluminium
Part Number: P-030H-012-100A Metric Timing Stock Pulleys - 12 tooth - 100x11.5 mm - Aluminium 1 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $86.23 AUD Regular price Sale price $86.23 AUD Unit price per Each
12	100.0 mm	11.50 mm	10.70
Material: Aluminium Pitch Dia. (PD): 6.30 mm Flange Diameter (FD): 22.0 mm Category: Pulleys - Metric Timing Stock - 3.000mm Pitch - HTD - Aluminium
Part Number: P-030H-012-100A Metric Timing Stock Pulleys - 12 tooth - 100x11.5 mm - Aluminium 1 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $86.23 AUD Regular price Sale price $86.23 AUD Unit price per Each View the product page first if you are unsure.
Pulleys - Metric Timin... P-030H-012-100A --- Metric Timing Stock Pulleys - 12 tooth - 100x11.5 mm - Aluminium P-030H-012-100A --- Metric Timing Stock Pulleys - 12 tooth - 100x11.5 mm - Aluminium Regular price $86.23 AUD Regular price Sale price $86.23 AUD Unit price per 1 Available Now
13	6.00 mm	4.000 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 12.41 mm Flange Diameter (FD): 15.5 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-013-060FF-AL-G-040 Metric Timing Pulleys - 13 tooth - 6x4 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $39.14 AUD Regular price Sale price $39.14 AUD Unit price per Each
13	6.00 mm	4.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 12.41 mm Flange Diameter (FD): 15.5 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-013-060FF-AL-G-040 Metric Timing Pulleys - 13 tooth - 6x4 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $39.14 AUD Regular price Sale price $39.14 AUD Unit price per Each View the product page first if you are unsure.
P-030H-013-060FF-AL-G-040 --- Metric Timing Pulleys - 13 tooth - 6x4 mm - Aluminium P-030H-013-060FF-AL-G-040 --- Metric Timing Pulleys - 13 tooth - 6x4 mm - Aluminium Regular price $39.14 AUD Regular price Sale price $39.14 AUD Unit price per 2 Available Now
14	6.00 mm	6.000 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-014-060FF-AL-G-060 Metric Timing Pulleys - 14 tooth - 6x6 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $38.86 AUD Regular price Sale price $38.86 AUD Unit price per Each
14	6.00 mm	6.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 14.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-014-060FF-AL-G-060 Metric Timing Pulleys - 14 tooth - 6x6 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $38.86 AUD Regular price Sale price $38.86 AUD Unit price per Each View the product page first if you are unsure.
P-030H-014-060FF-AL-G-060 --- Metric Timing Pulleys - 14 tooth - 6x6 mm - Aluminium P-030H-014-060FF-AL-G-060 --- Metric Timing Pulleys - 14 tooth - 6x6 mm - Aluminium Regular price $38.86 AUD Regular price Sale price $38.86 AUD Unit price per 2 Available Now
15	6.00 mm	5.000 mm	Finished	EZ-Lock Hub
Material: Aluminium Type: 2 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 17.4 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-015-060FF-AL-E-050 Metric Timing Pulleys - 15 tooth - 6x5 mm - Aluminium 5 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $71.50 AUD Regular price Sale price $71.50 AUD Unit price per Each
15	6.00 mm	5.000 mm	Finished
Material: Aluminium Locking Type: EZ-Lock Hub Type: 2 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 17.4 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-015-060FF-AL-E-050 Metric Timing Pulleys - 15 tooth - 6x5 mm - Aluminium 5 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $71.50 AUD Regular price Sale price $71.50 AUD Unit price per Each View the product page first if you are unsure.
P-030H-015-060FF-AL-E-050 --- Metric Timing Pulleys - 15 tooth - 6x5 mm - Aluminium P-030H-015-060FF-AL-E-050 --- Metric Timing Pulleys - 15 tooth - 6x5 mm - Aluminium Regular price $71.50 AUD Regular price Sale price $71.50 AUD Unit price per 5 Available Now
16	6.00 mm	4.763 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 15.27 mm Flange Diameter (FD): 18.3 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-016-060FF-AL-G-048 Metric Timing Pulleys - 16 tooth - 6x4.763 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $31.32 AUD Regular price ~~$37.58 AUD~~ Sale price $31.32 AUD Unit price per Each
16	6.00 mm	4.763 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 15.27 mm Flange Diameter (FD): 18.3 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-016-060FF-AL-G-048 Metric Timing Pulleys - 16 tooth - 6x4.763 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $31.32 AUD Regular price ~~$37.58 AUD~~ Sale price $31.32 AUD Unit price per Each View the product page first if you are unsure.
P-030H-016-060FF-AL-G-048 --- Metric Timing Pulleys - 16 tooth - 6x4.763 mm - Aluminium Sale P-030H-016-060FF-AL-G-048 --- Metric Timing Pulleys - 16 tooth - 6x4.763 mm - Aluminium Regular price $31.32 AUD Regular price ~~$37.58 AUD~~ Sale price $31.32 AUD Unit price per 2 Available Now Sale
16	6.00 mm	5.000 mm	Finished	EZ-Lock Hub
Material: Aluminium Type: 2 Pitch Dia. (PD): 15.27 mm Flange Diameter (FD): 18.0 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-016-060FF-AL-E-050 Metric Timing Pulleys - 16 tooth - 6x5 mm - Aluminium 93 Available Now \| Further orders can be expected around Sat, May 10, 2025 Regular price $47.50 AUD Regular price Sale price $47.50 AUD Unit price per Each
16	6.00 mm	5.000 mm	Finished
Material: Aluminium Locking Type: EZ-Lock Hub Type: 2 Pitch Dia. (PD): 15.27 mm Flange Diameter (FD): 18.0 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-016-060FF-AL-E-050 Metric Timing Pulleys - 16 tooth - 6x5 mm - Aluminium 93 Available Now \| Further orders can be expected around Sat, May 10, 2025 Regular price $47.50 AUD Regular price Sale price $47.50 AUD Unit price per Each View the product page first if you are unsure.
P-030H-016-060FF-AL-E-050 --- Metric Timing Pulleys - 16 tooth - 6x5 mm - Aluminium P-030H-016-060FF-AL-E-050 --- Metric Timing Pulleys - 16 tooth - 6x5 mm - Aluminium Regular price $47.50 AUD Regular price Sale price $47.50 AUD Unit price per 93 Available Now
26	6.00 mm	6.350 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 24.82 mm Flange Diameter (FD): 28.7 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-026-060FF-AL-G-064 Metric Timing Pulleys - 26 tooth - 6x6.35 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $38.14 AUD Regular price Sale price $38.14 AUD Unit price per Each
26	6.00 mm	6.350 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 24.82 mm Flange Diameter (FD): 28.7 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-026-060FF-AL-G-064 Metric Timing Pulleys - 26 tooth - 6x6.35 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $38.14 AUD Regular price Sale price $38.14 AUD Unit price per Each View the product page first if you are unsure.
P-030H-026-060FF-AL-G-064 --- Metric Timing Pulleys - 26 tooth - 6x6.35 mm - Aluminium P-030H-026-060FF-AL-G-064 --- Metric Timing Pulleys - 26 tooth - 6x6.35 mm - Aluminium Regular price $38.14 AUD Regular price Sale price $38.14 AUD Unit price per 3 Available Now
29	150.0 mm	27.70 mm	26.93
Material: Aluminium Pitch Dia. (PD): 12.70 mm Flange Diameter (FD): 19.0 mm Category: Pulleys - Metric Timing Stock - 3.000mm Pitch - HTD - Aluminium
Part Number: P-030H-029-150A Metric Timing Stock Pulleys - 29 tooth - 150x27.7 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $116.05 AUD Regular price Sale price $116.05 AUD Unit price per Each
29	150.0 mm	27.70 mm	26.93
Material: Aluminium Pitch Dia. (PD): 12.70 mm Flange Diameter (FD): 19.0 mm Category: Pulleys - Metric Timing Stock - 3.000mm Pitch - HTD - Aluminium
Part Number: P-030H-029-150A Metric Timing Stock Pulleys - 29 tooth - 150x27.7 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $116.05 AUD Regular price Sale price $116.05 AUD Unit price per Each View the product page first if you are unsure.
Pulleys - Metric Timin... P-030H-029-150A --- Metric Timing Stock Pulleys - 29 tooth - 150x27.7 mm - Aluminium P-030H-029-150A --- Metric Timing Stock Pulleys - 29 tooth - 150x27.7 mm - Aluminium Regular price $116.05 AUD Regular price Sale price $116.05 AUD Unit price per 2 Available Now
30	9.00 mm	6.000 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 31.8 mm Overall Length: 20.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-030-090FF-AL-G-060 Metric Timing Pulleys - 30 tooth - 9x6 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $30.95 AUD Regular price ~~$37.15 AUD~~ Sale price $30.95 AUD Unit price per Each
30	9.00 mm	6.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 31.8 mm Overall Length: 20.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-030-090FF-AL-G-060 Metric Timing Pulleys - 30 tooth - 9x6 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $30.95 AUD Regular price ~~$37.15 AUD~~ Sale price $30.95 AUD Unit price per Each View the product page first if you are unsure.
P-030H-030-090FF-AL-G-060 --- Metric Timing Pulleys - 30 tooth - 9x6 mm - Aluminium Sale P-030H-030-090FF-AL-G-060 --- Metric Timing Pulleys - 30 tooth - 9x6 mm - Aluminium Regular price $30.95 AUD Regular price ~~$37.15 AUD~~ Sale price $30.95 AUD Unit price per 3 Available Now Sale
30	9.00 mm	6.350 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 31.8 mm Overall Length: 20.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-030-090FF-AL-G-064 Metric Timing Pulleys - 30 tooth - 9x6.35 mm - Aluminium 4 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $46.50 AUD Regular price Sale price $46.50 AUD Unit price per Each
30	9.00 mm	6.350 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 31.8 mm Overall Length: 20.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-030-090FF-AL-G-064 Metric Timing Pulleys - 30 tooth - 9x6.35 mm - Aluminium 4 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $46.50 AUD Regular price Sale price $46.50 AUD Unit price per Each View the product page first if you are unsure.
P-030H-030-090FF-AL-G-064 --- Metric Timing Pulleys - 30 tooth - 9x6.35 mm - Aluminium P-030H-030-090FF-AL-G-064 --- Metric Timing Pulleys - 30 tooth - 9x6.35 mm - Aluminium Regular price $46.50 AUD Regular price Sale price $46.50 AUD Unit price per 4 Available Now
36	6.00 mm	6.000 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 34.36 mm Flange Diameter (FD): 37.4 mm Overall Length: 18.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-036-060FF-AL-G-060 Metric Timing Pulleys - 36 tooth - 6x6 mm - Aluminium 12 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $49.77 AUD Regular price Sale price $49.77 AUD Unit price per Each
36	6.00 mm	6.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 34.36 mm Flange Diameter (FD): 37.4 mm Overall Length: 18.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-036-060FF-AL-G-060 Metric Timing Pulleys - 36 tooth - 6x6 mm - Aluminium 12 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $49.77 AUD Regular price Sale price $49.77 AUD Unit price per Each View the product page first if you are unsure.
P-030H-036-060FF-AL-G-060 --- Metric Timing Pulleys - 36 tooth - 6x6 mm - Aluminium P-030H-036-060FF-AL-G-060 --- Metric Timing Pulleys - 36 tooth - 6x6 mm - Aluminium Regular price $49.77 AUD Regular price Sale price $49.77 AUD Unit price per 12 Available Now
40	6.00 mm	6.000 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 41.3 mm Overall Length: 18.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-040-060FF-AL-G-060 Metric Timing Pulleys - 40 tooth - 6x6 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $50.14 AUD Regular price Sale price $50.14 AUD Unit price per Each
40	6.00 mm	6.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 41.3 mm Overall Length: 18.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-040-060FF-AL-G-060 Metric Timing Pulleys - 40 tooth - 6x6 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $50.14 AUD Regular price Sale price $50.14 AUD Unit price per Each View the product page first if you are unsure.
P-030H-040-060FF-AL-G-060 --- Metric Timing Pulleys - 40 tooth - 6x6 mm - Aluminium P-030H-040-060FF-AL-G-060 --- Metric Timing Pulleys - 40 tooth - 6x6 mm - Aluminium Regular price $50.14 AUD Regular price Sale price $50.14 AUD Unit price per 2 Available Now
40	6.00 mm	6.350 mm	Finished	Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 41.3 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-040-060FF-AL-G-064 Metric Timing Pulleys - 40 tooth - 6x6.35 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $52.32 AUD Regular price Sale price $52.32 AUD Unit price per Each
40	6.00 mm	6.350 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 41.3 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-040-060FF-AL-G-064 Metric Timing Pulleys - 40 tooth - 6x6.35 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $52.32 AUD Regular price Sale price $52.32 AUD Unit price per Each View the product page first if you are unsure.
P-030H-040-060FF-AL-G-064 --- Metric Timing Pulleys - 40 tooth - 6x6.35 mm - Aluminium P-030H-040-060FF-AL-G-064 --- Metric Timing Pulleys - 40 tooth - 6x6.35 mm - Aluminium Regular price $52.32 AUD Regular price Sale price $52.32 AUD Unit price per 2 Available Now
48	9.00 mm	8.000 mm	Finished	Set Screw
Material: Aluminium Type: 3 Pitch Dia. (PD): 45.82 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-048-090P-AL-G-080 Metric Timing Pulleys - 48 tooth - 9x8 mm - Aluminium 1 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $58.23 AUD Regular price Sale price $58.23 AUD Unit price per Each
48	9.00 mm	8.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 3 Pitch Dia. (PD): 45.82 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-048-090P-AL-G-080 Metric Timing Pulleys - 48 tooth - 9x8 mm - Aluminium 1 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $58.23 AUD Regular price Sale price $58.23 AUD Unit price per Each View the product page first if you are unsure.
P-030H-048-090P-AL-G-080 --- Metric Timing Pulleys - 48 tooth - 9x8 mm - Aluminium P-030H-048-090P-AL-G-080 --- Metric Timing Pulleys - 48 tooth - 9x8 mm - Aluminium Regular price $58.23 AUD Regular price Sale price $58.23 AUD Unit price per 1 Available Now
48	9.00 mm	15.875 mm		Shaftloc -tm- (Sleeve sold separately)
Material: Nylon (Polyamide 6/6) Type: Fig 2 Pitch Dia. (PD): 45.82 mm Flange Diameter (FD): 48.8 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-048-090FF-PN-SL-159 Metric Timing Pulleys - 48 tooth - 9x15.875 mm - Nylon (Polyamide 6/6) 1 Available Now \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $9.36 AUD Regular price ~~$17.79 AUD~~ Sale price $9.36 AUD Unit price per Each
48	9.00 mm	15.875 mm
Material: Nylon (Polyamide 6/6) Locking Type: Shaftloc -tm- (Sleeve sold separately) Type: Fig 2 Pitch Dia. (PD): 45.82 mm Flange Diameter (FD): 48.8 mm Overall Length: 14.3 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-048-090FF-PN-SL-159 Metric Timing Pulleys - 48 tooth - 9x15.875 mm - Nylon (Polyamide 6/6) 1 Available Now \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $9.36 AUD Regular price ~~$17.79 AUD~~ Sale price $9.36 AUD Unit price per Each
P-030H-048-090FF-PN-SL-159 --- Metric Timing Pulleys - 48 tooth - 9x15.875 mm - Nylon (Polyamide 6/6) Sale P-030H-048-090FF-PN-SL-159 --- Metric Timing Pulleys - 48 tooth - 9x15.875 mm - Nylon (Polyamide 6/6) Regular price $9.36 AUD Regular price ~~$17.79 AUD~~ Sale price $9.36 AUD Unit price per 1 Available Now Sale
60	6.00 mm	8.000 mm	Finished	Set Screw
Material: Aluminium Type: 3 Pitch Dia. (PD): 57.27 mm Overall Length: 18.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-060-060P-AL-G-080 Metric Timing Pulleys - 60 tooth - 6x8 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $73.95 AUD Regular price Sale price $73.95 AUD Unit price per Each
60	6.00 mm	8.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 3 Pitch Dia. (PD): 57.27 mm Overall Length: 18.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 6mm Wide
Part Number: P-030H-060-060P-AL-G-080 Metric Timing Pulleys - 60 tooth - 6x8 mm - Aluminium 2 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $73.95 AUD Regular price Sale price $73.95 AUD Unit price per Each View the product page first if you are unsure.
P-030H-060-060P-AL-G-080 --- Metric Timing Pulleys - 60 tooth - 6x8 mm - Aluminium P-030H-060-060P-AL-G-080 --- Metric Timing Pulleys - 60 tooth - 6x8 mm - Aluminium Regular price $73.95 AUD Regular price Sale price $73.95 AUD Unit price per 2 Available Now
60	9.00 mm	7.938 mm	Finished	Set Screw
Material: Aluminium Type: 3 Pitch Dia. (PD): 57.27 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090P-AL-G-079 Metric Timing Pulleys - 60 tooth - 9x7.938 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $78.86 AUD Regular price Sale price $78.86 AUD Unit price per Each
60	9.00 mm	7.938 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 3 Pitch Dia. (PD): 57.27 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090P-AL-G-079 Metric Timing Pulleys - 60 tooth - 9x7.938 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $78.86 AUD Regular price Sale price $78.86 AUD Unit price per Each View the product page first if you are unsure.
P-030H-060-090P-AL-G-079 --- Metric Timing Pulleys - 60 tooth - 9x7.938 mm - Aluminium P-030H-060-090P-AL-G-079 --- Metric Timing Pulleys - 60 tooth - 9x7.938 mm - Aluminium Regular price $78.86 AUD Regular price Sale price $78.86 AUD Unit price per 3 Available Now
60	9.00 mm	8.000 mm	Finished	Set Screw
Material: Aluminium Type: 3 Pitch Dia. (PD): 57.27 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090P-AL-G-080 Metric Timing Pulleys - 60 tooth - 9x8 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $73.32 AUD Regular price Sale price $73.32 AUD Unit price per Each
60	9.00 mm	8.000 mm	Finished
Material: Aluminium Locking Type: Set Screw Type: 3 Pitch Dia. (PD): 57.27 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090P-AL-G-080 Metric Timing Pulleys - 60 tooth - 9x8 mm - Aluminium 3 Available Now \| Further orders can be expected around Fri, May 30, 2025 Regular price $73.32 AUD Regular price Sale price $73.32 AUD Unit price per Each View the product page first if you are unsure.
P-030H-060-090P-AL-G-080 --- Metric Timing Pulleys - 60 tooth - 9x8 mm - Aluminium P-030H-060-090P-AL-G-080 --- Metric Timing Pulleys - 60 tooth - 9x8 mm - Aluminium Regular price $73.32 AUD Regular price Sale price $73.32 AUD Unit price per 3 Available Now
60	9.00 mm	12.000 mm		Set Screw, Aluminium Insert
Material: Plastic Type: Fig 3 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 63.0 mm Overall Length: 20.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090SF-PP-GAI-120 Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic 1 Available Now \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $8.15 AUD Regular price ~~$15.49 AUD~~ Sale price $8.15 AUD Unit price per Each
60	9.00 mm	12.000 mm
Material: Plastic Locking Type: Set Screw, Aluminium Insert Type: Fig 3 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 63.0 mm Overall Length: 20.6 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090SF-PP-GAI-120 Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic 1 Available Now \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $8.15 AUD Regular price ~~$15.49 AUD~~ Sale price $8.15 AUD Unit price per Each
P-030H-060-090SF-PP-GAI-120 --- Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic Sale P-030H-060-090SF-PP-GAI-120 --- Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic Regular price $8.15 AUD Regular price ~~$15.49 AUD~~ Sale price $8.15 AUD Unit price per 1 Available Now Sale
60	9.00 mm	12.000 mm		Set Screw, Aluminium Insert
Material: Plastic Type: Fig 9 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 63.0 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090FF-PP-GAI-120 Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic 1 Available Now \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $11.73 AUD Regular price ~~$22.28 AUD~~ Sale price $11.73 AUD Unit price per Each
60	9.00 mm	12.000 mm
Material: Plastic Locking Type: Set Screw, Aluminium Insert Type: Fig 9 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 63.0 mm Overall Length: 22.2 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide
Part Number: P-030H-060-090FF-PP-GAI-120 Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic 1 Available Now \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $11.73 AUD Regular price ~~$22.28 AUD~~ Sale price $11.73 AUD Unit price per Each
P-030H-060-090FF-PP-GAI-120 --- Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic Sale P-030H-060-090FF-PP-GAI-120 --- Metric Timing Pulleys - 60 tooth - 9x12 mm - Plastic Regular price $11.73 AUD Regular price ~~$22.28 AUD~~ Sale price $11.73 AUD Unit price per 1 Available Now Sale
