Mounts - Levelling Socket - Swivel - 303 Stainless Acetal Base

Mounts -> Levelling Socket -> Swivel -> 303 Stainless Acetal Base

There is only 1 product in the sub-categories of Mounts - Levelling Socket - Swivel - 303 Stainless Acetal Base. Browse the Mounts - Levelling Socket - Swivel - 303 Stainless Acetal Base products table.

Category Details

A selection of 303 Stainless Acetal Base Swivel Levelling Socket Mounts. Levelling adjusters. 15o swivel off centreline to adjust to uneven surfaces and level machine tools, electronic racks and benches.

  • An expanded range may be available on special order. Please enquire.

Small Parts & Bearings

Additional resources:


A more comprehensive listing may be found in the Mounts - Levelling Socket - Swivel - 303 Stainless Acetal Base category on the MBA Minibearings main store.
Thread Size (A) Base Diameter (D) Foot Height (C) Min. Thread Depth Base Height (E) Overall Height Indicative
Levelling Socket Mounts - 10-32 UNF - 4.76mm - 19.1x13.5 mm Swivel - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Mount
Thread Size (A)
10-32 UNF (4.76mm)

Base Diameter (D)
19.1
mm

(Equiv. 0.752 in.)
Foot Height (C)
13.5
mm

(Equiv. 0.531 in.)
Min. Thread Depth
4.3
mm
Base Height (E)
2.79
mm
Levelling Socket Mounts - 10-32 UNF -4.76mm- 19.1x13.5 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80    Load Rating: 70 Kg    Pad Material: Delrin    Hex Flats (B): 9.53 mm
Part Number: MSF-048F-S3AP (Each)
Out of Stock | Backorder Now | Orders can be expected around Tue, Jan 20, 2026
$25.23 AUD
$25.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Thread Size (A) Base Diameter (D) Foot Height (C) Min. Thread Depth Indicative
Levelling Socket Mounts - 10-32 UNF - 4.76mm - 19.1x13.5 mm Swivel - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Mount
Thread Size (A)
10-32 UNF (4.76mm)

Base Diameter (D)
19.1
mm

(Equiv. 0.752 in.)
Foot Height (C)
13.5
mm

(Equiv. 0.531 in.)
Min. Thread Depth
4.3
mm
Levelling Socket Mounts - 10-32 UNF -4.76mm- 19.1x13.5 mm - Stainless Steel 303/304 Similar to A2, 18-8 HRB80
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80    Base Height (E): 2.79 mm    Load Rating: 70 Kg    Pad Material: Delrin    Hex Flats (B): 9.53 mm
Part Number: MSF-048F-S3AP (Each)
Out of Stock | Backorder Now | Orders can be expected around Tue, Jan 20, 2026
$25.23 AUD
$25.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
