Collection: Linear - Rail Systems Type 2 Carriage
Linear -> Rail Systems Type 2 CarriageThere are 2 products in the sub-categories of Linear - Rail Systems Type 2 Carriage. Browse the Linear - Rail Systems Type 2 Carriage products table. To narrow down the selection, please choose a sub-category from the links below.
Linear - Rail Systems Type 2 Carriage - Narrow
A selection of Narrow Rail Systems Type 2 Carriage Linear. Match with...
Linear - Rail Systems Type 2 Carriage - Standard
A selection of Standard Rail Systems Type 2 Carriage Linear. Match with...
Category Details
This category includes various types of rail systems type 2 carriage linear.
- High load linear guides. Crowned rollers prevent roller edge loading when misalignment is present.
- High rigidity from back to back four roller track arrangement. Smooth, quiet movement through patented insert molded recirculation paths and optimized geometries.
- Applications include industrial automation, material handling, machine & tool equipment and more.
Small Parts & Bearings
Additional resources:
A more comprehensive listing may be found in the Linear - Rail Systems Type 2 Carriage category on the MBA Minibearings main store.
| Size Reference | Height (A) | Width (B) | Rail Width (B1) | B8 | Bolt Centres Width (N) |
Indicative Image |
|---|---|---|---|---|---|---|
| Rail Systems Type 2 Carriage Linear - Size Reference 15 - 24x34 mm Narrow | ||||||
|
Size Reference
15
|
Height (A)
24.000
mm (Equiv. 0.945 in.) |
Width (B)
34.000
mm (Equiv. 1.339 in.) |
Rail Width (B1)
15.000
mm |
B8
9.500
mm |
Bolt Centres Width (N)
26.000
mm |
|
|
Carriage Height (J): 20.200 mm
Bolt Depth (G): 5.000 mm
Category: Linear - Rail Systems Type 2 Carriage - Narrow |
||||||
|
Part Number: TLM-3102RS (Each)
Out of Stock | Backorder Now | Orders can be expected around Tue, Feb 03, 2026 Regular price
$782.50 AUD
Regular price
Unit price
per
Each
Excludes GST and overseas Taxes & Duties |
||||||
| Size Reference | Height (A) | Width (B) | Rail Width (B1) |
Indicative Image |
||
| Rail Systems Type 2 Carriage Linear - Size Reference 15 - 24x34 mm Narrow | ||||||
|
Size Reference
15
|
Height (A)
24.000
mm (Equiv. 0.945 in.) |
Width (B)
34.000
mm (Equiv. 1.339 in.) |
Rail Width (B1)
15.000
mm |
|
||
|
B8: 9.500 mm
Bolt Centres Width (N): 26.000 mm
Carriage Height (J): 20.200 mm
Bolt Depth (G): 5.000 mm
Category: Linear - Rail Systems Type 2 Carriage - Narrow |
||||||
|
Part Number: TLM-3102RS (Each)
Out of Stock | Backorder Now | Orders can be expected around Tue, Feb 03, 2026 Regular price
$782.50 AUD
Regular price
Unit price
per
Each
Excludes GST and overseas Taxes & Duties |
||||||
|
||||||
| Rail Systems Type 2 Carriage Linear - Size Reference 15 - 24x47 mm Standard | ||||||
|
Size Reference
15
|
Height (A)
24.000
mm (Equiv. 0.945 in.) |
Width (B)
47.000
mm (Equiv. 1.85 in.) |
Rail Width (B1)
15.000
mm |
B8
16.000
mm |
Bolt Centres Width (N)
38.000
mm |
|
|
Carriage Height (J): 20.200 mm
Bolt Depth (G): 7.000 mm
Category: Linear - Rail Systems Type 2 Carriage - Standard |
||||||
|
Part Number: TLM-3096RS (Each)
Out of Stock | Backorder Now | Orders can be expected around Tue, Feb 03, 2026 Regular price
$782.50 AUD
Regular price
Unit price
per
Each
Excludes GST and overseas Taxes & Duties |
||||||
| Rail Systems Type 2 Carriage Linear - Size Reference 15 - 24x47 mm Standard | ||||||
|
Size Reference
15
|
Height (A)
24.000
mm (Equiv. 0.945 in.) |
Width (B)
47.000
mm (Equiv. 1.85 in.) |
Rail Width (B1)
15.000
mm |
|
||
|
B8: 16.000 mm
Bolt Centres Width (N): 38.000 mm
Carriage Height (J): 20.200 mm
Bolt Depth (G): 7.000 mm
Category: Linear - Rail Systems Type 2 Carriage - Standard |
||||||
|
Part Number: TLM-3096RS (Each)
Out of Stock | Backorder Now | Orders can be expected around Tue, Feb 03, 2026 Regular price
$782.50 AUD
Regular price
Unit price
per
Each
Excludes GST and overseas Taxes & Duties |
||||||
|
||||||
