Leadscrew - Nut Flanges - For Acme Supernuts

1 Item Available
  • Flanges for Acme leadscrew thread supernuts metric and imperial
  • MATERIAL - Aluminum 6062-T6
  • These flanges are screwed onto the outer thread of the red leadscrew nuts
  • This provides a mounting surface to enable location of the leadscrew nut on the surface to be moved
Additional resources:

A more comprehensive listing may be found on the MBA Minibearings main store at Leadscrew - Nut Flanges - For Acme Supernuts.
Suits Nut Mounting Thread Flange OD (A) Flange Thickness (B) Mounting Hole Diameter (D) Mounting Hole Diameter (C) Indicative
9/16-18 UNF (14.29mm)
40.64
mm 		6.350
mm 		4.50
mm 		31.5
mm 		1085853 | HB250F-025 --- Nut Flanges Leadscrew - 9/16-18 UNF -14.29mm- 40.64x6.35 mm
Part Number: HB250F-025 Nut Flanges Leadscrew - 9/16-18 UNF -14.29mm- 40.64x6.35 mm
2 Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$46.00 AUD
$87.40 AUD $46.00 AUD
Each
Suits Nut Mounting Thread Flange OD (A) Flange Thickness (B) Mounting Hole Diameter (D) Indicative
9/16-18 UNF (14.29mm)
40.64
mm 		6.350
mm 		4.50
mm 		1085853 | HB250F-025 --- Nut Flanges Leadscrew - 9/16-18 UNF -14.29mm- 40.64x6.35 mm
Mounting Hole Diameter (C): 31.5 mm
Part Number: HB250F-025 Nut Flanges Leadscrew - 9/16-18 UNF -14.29mm- 40.64x6.35 mm
2 Available Now | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$46.00 AUD
$87.40 AUD $46.00 AUD
Each
