Bearings - Tapered Roller Set - Single Row - Metric

Bearings -> Tapered Roller Set -> Single Row -> Metric

There are 3 products in the sub-categories of Bearings - Tapered Roller Set - Single Row - Metric. Browse the Bearings - Tapered Roller Set - Single Row - Metric products table.

Category Details

A selection of Metric Single Row Tapered Roller Set Bearings. Includes cup and cone

  • Tapered roller bearings provide for high thrust and axial loads, and are commonly used in automotive applications such as wheels, differentials and gearboxes.
  • Matched sets include the cup and the cone.
  • An expanded range may be available on special order. Please enquire.

Small Parts & Bearings

Additional resources:


A more comprehensive listing may be found in the Bearings - Tapered Roller Set - Single Row - Metric category on the MBA Minibearings main store.
Inside Diameter Outside Diameter Assembled Width Cone Width Cup Width Radius Cone (min) Indicative
Tapered Roller Set Bearings - 15x35x11.75 mm / 11 mm Single Row - Chrome Steel Bearing
Inside Diameter
15
mm

(Equiv. 0.591 in.)
Outside Diameter
35
mm

(Equiv. 1.378 in.)
Assembled Width
11.750
mm

(Equiv. 0.463 in.)
Cone Width
11
mm
Cup Width
10
mm
Radius Cone (min)
0.600
mm
Tapered Roller Set Bearings - 15x35x11.75 mm / 11 mm - Chrome Steel
Material: Chrome Steel    Radius Cup (min): 0.600 mm    Basic Dynamic Load: 14800 N    Basic Static Load: 14100 N    Limiting Speed for Grease: 11000    Limiting Speed for Oil: 15000
Part Number: E30202J (Each)
1 Available Now | Further orders can be expected around Thu, Jan 08, 2026
$20.05 AUD
$20.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Larger quantities than the 1 available can be backordered.
Inside Diameter Outside Diameter Assembled Width Cone Width Indicative
Tapered Roller Set Bearings - 15x35x11.75 mm / 11 mm Single Row - Chrome Steel Bearing
Inside Diameter
15
mm

(Equiv. 0.591 in.)
Outside Diameter
35
mm

(Equiv. 1.378 in.)
Assembled Width
11.750
mm

(Equiv. 0.463 in.)
Cone Width
11
mm
Tapered Roller Set Bearings - 15x35x11.75 mm / 11 mm - Chrome Steel
Material: Chrome Steel    Cup Width: 10 mm    Radius Cone (min): 0.600 mm    Radius Cup (min): 0.600 mm    Basic Dynamic Load: 14800 N    Basic Static Load: 14100 N    Limiting Speed for Grease: 11000    Limiting Speed for Oil: 15000
Part Number: E30202J (Each)
1 Available Now | Further orders can be expected around Thu, Jan 08, 2026
$20.05 AUD
$20.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

1 Available Now. Backorder if more than 1.
Tapered Roller Set Bearings - 50x80x20 mm / 20 mm Single Row - Chrome Steel Bearing
Inside Diameter
50
mm

(Equiv. 1.969 in.)
Outside Diameter
80
mm

(Equiv. 3.15 in.)
Assembled Width
20
mm

(Equiv. 0.787 in.)
Cone Width
20
mm
Cup Width
15.500
mm
Radius Cone (min)
1
mm
Tapered Roller Set Bearings - 50x80x20 mm / 20 mm - Chrome Steel
Material: Chrome Steel    Radius Cup (min): 1 mm    Basic Dynamic Load: 62000 N    Basic Static Load: 90500 N    Limiting Speed for Grease: 4400    Limiting Speed for Oil: 6000
Part Number: E32010J (Each)
1 Available Now | Further orders can be expected around Thu, Jan 08, 2026
$26.05 AUD
$47.79 AUD $26.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Larger quantities than the 1 available can be backordered.
Tapered Roller Set Bearings - 50x80x20 mm / 20 mm Single Row - Chrome Steel Bearing
Inside Diameter
50
mm

(Equiv. 1.969 in.)
Outside Diameter
80
mm

(Equiv. 3.15 in.)
Assembled Width
20
mm

(Equiv. 0.787 in.)
Cone Width
20
mm
Tapered Roller Set Bearings - 50x80x20 mm / 20 mm - Chrome Steel
Material: Chrome Steel    Cup Width: 15.500 mm    Radius Cone (min): 1 mm    Radius Cup (min): 1 mm    Basic Dynamic Load: 62000 N    Basic Static Load: 90500 N    Limiting Speed for Grease: 4400    Limiting Speed for Oil: 6000
Part Number: E32010J (Each)
1 Available Now | Further orders can be expected around Thu, Jan 08, 2026
$26.05 AUD
$47.79 AUD $26.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

1 Available Now. Backorder if more than 1.
Tapered Roller Set Bearings - 50x110x42.25 mm / 40 mm Single Row - Chrome Steel Bearing
Inside Diameter
50
mm

(Equiv. 1.969 in.)
Outside Diameter
110
mm

(Equiv. 4.331 in.)
Assembled Width
42.250
mm

(Equiv. 1.663 in.)
Cone Width
40
mm
Cup Width
33
mm
Radius Cone (min)
2.500
mm
Tapered Roller Set Bearings - 50x110x42.25 mm / 40 mm - Chrome Steel
Material: Chrome Steel    Radius Cup (min): 2 mm    Basic Dynamic Load: 175000 N    Basic Static Load: 219000 N    Limiting Speed for Grease: 3600    Limiting Speed for Oil: 4800
Deleted Item. Available while stocks last.
Part Number: E32310J (Each)
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$40.99 AUD
$126.13 AUD $40.99 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
Tapered Roller Set Bearings - 50x110x42.25 mm / 40 mm Single Row - Chrome Steel Bearing
Inside Diameter
50
mm

(Equiv. 1.969 in.)
Outside Diameter
110
mm

(Equiv. 4.331 in.)
Assembled Width
42.250
mm

(Equiv. 1.663 in.)
Cone Width
40
mm
Tapered Roller Set Bearings - 50x110x42.25 mm / 40 mm - Chrome Steel
Material: Chrome Steel    Cup Width: 33 mm    Radius Cone (min): 2.500 mm    Radius Cup (min): 2 mm    Basic Dynamic Load: 175000 N    Basic Static Load: 219000 N    Limiting Speed for Grease: 3600    Limiting Speed for Oil: 4800
Deleted Item. Available while stocks last.
Part Number: E32310J (Each)
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$40.99 AUD
$126.13 AUD $40.99 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
