Bearings - Grooved OD - U Groove

12 Products in this selection
  • Special OD Bearings.
  • Contact us for tolerances.
ID (d) OD (D) Width (B) Inner Ring Width (Bn) Groove Base Diameter (GD) Groove Width (GB) Indicative
3.000
mm 		10.000
mm 		4.000
mm 		1046893 | U623-ZZ-09-ECO (2 Pcs) --- Bearings - 3 mm x 10 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 8.8 mm
Part Number: U623-ZZ-09-ECO (2 Pcs) Bearings - 3 mm x 10 mm x 4 mm
68 units (136 pcs) Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$7.05 AUD
$7.05 AUD
Per 2
ID (d) OD (D) Width (B) Inner Ring Width (Bn) Indicative
3.000
mm 		10.000
mm 		4.000
mm 		1046893 | U623-ZZ-09-ECO (2 Pcs) --- Bearings - 3 mm x 10 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 8.8 mm
Part Number: U623-ZZ-09-ECO (2 Pcs) Bearings - 3 mm x 10 mm x 4 mm
68 units (136 pcs) Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$7.05 AUD
$7.05 AUD
Per 2
4.000
mm 		12.000
mm 		4.000
mm 		1054595 | U604-ZZ-10-ECO (2 Pcs) --- Bearings - 4 mm x 12 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 10.0 mm
Part Number: U604-ZZ-10-ECO (2 Pcs) Bearings - 4 mm x 12 mm x 4 mm
16 units (32 pcs) Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$6.50 AUD
$6.50 AUD
Per 2
4.000
mm 		12.000
mm 		4.000
mm 		1054595 | U604-ZZ-10-ECO (2 Pcs) --- Bearings - 4 mm x 12 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 10.0 mm
Part Number: U604-ZZ-10-ECO (2 Pcs) Bearings - 4 mm x 12 mm x 4 mm
16 units (32 pcs) Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$6.50 AUD
$6.50 AUD
Per 2
4.000
mm 		12.000
mm 		4.000
mm 		5.000
mm 		1054623 | UW604A-ZZ-11-ECO (2 Pcs) --- Bearings - 4 mm x 12 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 10.5 mm
Part Number: UW604A-ZZ-11-ECO (2 Pcs) Bearings - 4 mm x 12 mm x 4 mm
24 units (48 pcs) Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$6.50 AUD
$6.50 AUD
Per 2
4.000
mm 		12.000
mm 		4.000
mm 		5.000
mm 		1054623 | UW604A-ZZ-11-ECO (2 Pcs) --- Bearings - 4 mm x 12 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 10.5 mm
Part Number: UW604A-ZZ-11-ECO (2 Pcs) Bearings - 4 mm x 12 mm x 4 mm
24 units (48 pcs) Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$6.50 AUD
$6.50 AUD
Per 2
4.000
mm 		13.000
mm 		4.000
mm 		1054773 | U624A-ZZ-12-ECO (2 Pcs) --- Bearings - 4 mm x 13 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 12.0 mm
Part Number: U624A-ZZ-12-ECO (2 Pcs) Bearings - 4 mm x 13 mm x 4 mm
22 units (44 pcs) Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$6.50 AUD
$6.50 AUD
Per 2
4.000
mm 		13.000
mm 		4.000
mm 		1054773 | U624A-ZZ-12-ECO (2 Pcs) --- Bearings - 4 mm x 13 mm x 4 mm
Material: Chrome Steel    Approx Groove Width: 2.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 12.0 mm
Part Number: U624A-ZZ-12-ECO (2 Pcs) Bearings - 4 mm x 13 mm x 4 mm
22 units (44 pcs) Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$6.50 AUD
$6.50 AUD
Per 2
4.000
mm 		13.000
mm 		4.000
mm 		1054775 | US624A-ZZ-11 --- Bearings - 4 mm x 13 mm x 4 mm
Material: AIS I 440C Stainless Steel    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 11.0 mm    Groove Radius (+/- 0.05) (GR): 1.250 mm
Part Number: US624A-ZZ-11 Bearings - 4 mm x 13 mm x 4 mm
200 Available
| Backorders for more can be expected around Thu, Feb 27, 2025
$13.95 AUD
$13.95 AUD
Each
4.000
mm 		13.000
mm 		4.000
mm 		1054775 | US624A-ZZ-11 --- Bearings - 4 mm x 13 mm x 4 mm
Material: AIS I 440C Stainless Steel    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 11.0 mm    Groove Radius (+/- 0.05) (GR): 1.250 mm
Part Number: US624A-ZZ-11 Bearings - 4 mm x 13 mm x 4 mm
200 Available
| | Backorders for more can be expected around Thu, Feb 27, 2025
$13.95 AUD
$13.95 AUD
Each
4.000
mm 		13.000
mm 		5.000
mm 		1054792 | U624-ZZ-12-ECO (5 Pcs) --- Bearings - 4 mm x 13 mm x 5 mm
Material: Chrome Steel    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 12.3 mm    Groove Radius (+/- 0.05) (GR): 0.350 mm
Part Number: U624-ZZ-12-ECO (5 Pcs) Bearings - 4 mm x 13 mm x 5 mm
1 pack (5 pcs) Available
Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$8.00 AUD
$0.00 AUD $8.00 AUD
Per 5
4.000
mm 		13.000
mm 		5.000
mm 		1054792 | U624-ZZ-12-ECO (5 Pcs) --- Bearings - 4 mm x 13 mm x 5 mm
Material: Chrome Steel    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 12.3 mm    Groove Radius (+/- 0.05) (GR): 0.350 mm
Part Number: U624-ZZ-12-ECO (5 Pcs) Bearings - 4 mm x 13 mm x 5 mm
1 pack (5 pcs) Available
Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity |
$8.00 AUD
$0.00 AUD $8.00 AUD
Per 5
4.000
mm 		13.000
mm 		7.000
mm 		1054869 | U624C-ZZ-10-SG (5 Pcs) --- Bearings - 4 mm x 13 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 5.5 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 9.5 mm
Part Number: U624C-ZZ-10-SG (5 Pcs) Bearings - 4 mm x 13 mm x 7 mm
66 units (330 pcs) Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$6.95 AUD
$6.95 AUD
Per 5
4.000
mm 		13.000
mm 		7.000
mm 		1054869 | U624C-ZZ-10-SG (5 Pcs) --- Bearings - 4 mm x 13 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 5.5 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 9.5 mm
Part Number: U624C-ZZ-10-SG (5 Pcs) Bearings - 4 mm x 13 mm x 7 mm
66 units (330 pcs) Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$6.95 AUD
$6.95 AUD
Per 5
4.000
mm 		13.000
mm 		7.000
mm 		1054870 | U624C-ZZ-09-ECO --- Bearings - 4 mm x 13 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 5.5 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 9.0 mm
Part Number: U624C-ZZ-09-ECO Bearings - 4 mm x 13 mm x 7 mm
50 Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$5.14 AUD
$5.14 AUD
Each
4.000
mm 		13.000
mm 		7.000
mm 		1054870 | U624C-ZZ-09-ECO --- Bearings - 4 mm x 13 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 5.5 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 9.0 mm
Part Number: U624C-ZZ-09-ECO Bearings - 4 mm x 13 mm x 7 mm
50 Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$5.14 AUD
$5.14 AUD
Each
4.000
mm 		16.500
mm 		7.000
mm 		1055227 | UMR165-4-ZZ-14-ECO --- Bearings - 4 mm x 16.5 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 4.5 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 13.5 mm
Part Number: UMR165-4-ZZ-14-ECO Bearings - 4 mm x 16.5 mm x 7 mm
102 Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$5.14 AUD
$5.14 AUD
Each
4.000
mm 		16.500
mm 		7.000
mm 		1055227 | UMR165-4-ZZ-14-ECO --- Bearings - 4 mm x 16.5 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 4.5 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 13.5 mm
Part Number: UMR165-4-ZZ-14-ECO Bearings - 4 mm x 16.5 mm x 7 mm
102 Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$5.14 AUD
$5.14 AUD
Each
4.000
mm 		18.000
mm 		7.000
mm 		8.000
mm 		1055256 | UWMR184A-ZZ-13-ECO --- Bearings - 4 mm x 18 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 5.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 13.0 mm
Part Number: UWMR184A-ZZ-13-ECO Bearings - 4 mm x 18 mm x 7 mm
71 Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$5.14 AUD
$5.14 AUD
Each
4.000
mm 		18.000
mm 		7.000
mm 		8.000
mm 		1055256 | UWMR184A-ZZ-13-ECO --- Bearings - 4 mm x 18 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 5.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 13.0 mm
Part Number: UWMR184A-ZZ-13-ECO Bearings - 4 mm x 18 mm x 7 mm
71 Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$5.14 AUD
$5.14 AUD
Each
4.000
mm 		20.000
mm 		5.000
mm 		1055315 | USMR204-ZZ-18 (50 Pcs) --- Bearings - 4 mm x 20 mm x 5 mm
Material: AIS I 440C Stainless Steel    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 18.0 mm    Groove Radius (+/- 0.05) (GR): 1.000 mm
Part Number: USMR204-ZZ-18 (50 Pcs) Bearings - 4 mm x 20 mm x 5 mm
Out of Stock
Backorder Now | Backorders for more can be expected around Thu, Jan 02, 2025
$1,407.14 AUD
$1,407.14 AUD
Per 50
4.000
mm 		20.000
mm 		5.000
mm 		1055315 | USMR204-ZZ-18 (50 Pcs) --- Bearings - 4 mm x 20 mm x 5 mm
Material: AIS I 440C Stainless Steel    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 18.0 mm    Groove Radius (+/- 0.05) (GR): 1.000 mm
Part Number: USMR204-ZZ-18 (50 Pcs) Bearings - 4 mm x 20 mm x 5 mm
Out of Stock
Backorder Now | | Backorders for more can be expected around Thu, Jan 02, 2025
$1,407.14 AUD
$1,407.14 AUD
Per 50
5.000
mm 		16.000
mm 		7.000
mm 		8.000
mm 		1063762 | U625A-ZZ-13-ECO --- Bearings - 5 mm x 16 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 3.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 13.5 mm
Part Number: U625A-ZZ-13-ECO Bearings - 5 mm x 16 mm x 7 mm
35 Available
| Backorders for more can be expected around Fri, Dec 27, 2024
$5.50 AUD
$5.50 AUD
Each
5.000
mm 		16.000
mm 		7.000
mm 		8.000
mm 		1063762 | U625A-ZZ-13-ECO --- Bearings - 5 mm x 16 mm x 7 mm
Material: Chrome Steel    Approx Groove Width: 3.0 mm    Closures: ZZ    Type: U-Groove Profile    Groove Base Diameter (GD): 13.5 mm
Part Number: U625A-ZZ-13-ECO Bearings - 5 mm x 16 mm x 7 mm
35 Available
| | Backorders for more can be expected around Fri, Dec 27, 2024
$5.50 AUD
$5.50 AUD
Each
