Miniature Bearings Australia
STR-318-0191-1219-CST - Datasheet
MBA
Category Information
Strip - Spring SteelSpring Steel Strip. Hundreds of uses.
- An expanded range may be available on special order. Please enquire.
- Hardened and tempered spring steel strip
- Note that the width of this strip may vary up to a few mm as it is guillotine cut from sheet
- If you require a closer tolerance on the strip width please contact us prior to ordering
- Appearance can be blue, grey-brown, or bright steel colour.
Product Data
- Thickness (t)
:
3.18
mm
+/- 0.051
(Equiv. 0.125 in.) - Width (w)
19.1
mm
+/- 1.6
(Equiv. 0.752 in.) - Length (L)
1219.2
mm
Minimum
(Equiv. 48 in.) - Description Strip
- Grade SAE1075
- Typical Hardness 45 RC
- Appearance May be blue, grey-brown, or bright steel colour.
- Material Carbon Spring Steel
