Miniature Bearings Australia
OR-01999-533-CR70-315 - Datasheet
MBA
Category Information
O-Rings - General Purpose - Neoprene Rubber PacksNeoprene Rubber Packs General Purpose O-Rings. Excellent resistance to ageing and weathering effects.
- Mulitple packs may be supplied together in a singular package.
- Temperature Range: -20 Deg C to +100 Deg C.
- Resistant to ozone and refrigeration chemicals such as freon 12 and 22.
- Moderate resistance to swelling in mineral oils, greases and water.
- Not resistant to aromatic compounds such as benzene, toulene, chlorinated hydrocarbons, esters, ethers or ketones.
- If you need a larger quantity, please check the BULK category for these o-rings.
Product Data
- Inside Diameter (ID)
:
19.99
mm
(Equiv. 0.787 in.) - Section (t)
5.33
mm
(Equiv. 0.21 in.) - Colour Black
- Hardness Duro 70
- Material Neoprene Rubber
Product Compliance and Data
Additional Resources
Cross References
- ORB-01999-533-CR70-315
- ORB01999533CR70315
- BS315-CR70
- BS315CR70
