Collection: Bearings - Plastic - Acetal - Single Row - Glass Balls

Bearings (With Images)

Plastic

Acetal

Single Row

32 Products in this selection

A selection of Glass Balls Single Row Acetal Plastic Bearings. Bearings for Extreme Corrosion Resistance - Low Speed - Low Load.

Plastic ball bearings do not use the same precision standards as those for precision ball bearings
Races made from Acetal - Balls made from Ground Glass - Cages from Acetal or Nylon.
Lubrication - Water Lubrication or can be run dry - Must lubricate over 2500 RPM.
Temperature Range - Minus 30 ^oC to 100 ^oC Continuous.

Small Parts & Bearings

Additional resources:
Tolerances
Plastic Bearings PDF Catalogue
Shafting

A more comprehensive listing may be found on the MBA Minibearings main store at Bearings - Plastic - Acetal - Single Row - Glass Balls.

ID (d)	OD (D)	Width (B)	Flange Diameter	Flange Thickness
ID (d) 17.000 mm _{+ 0.076 / - 0.000} (Equiv. 0.669 in.)	OD (D) 35.000 mm _{+ 0.000 / - 0.102} (Equiv. 1.378 in.)	Width (B) 8.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.315 in.)
Material: Acetal with Glass Balls Max RPM in Air: 1069 Notes: Unlubricated Type: Radial Dynamic Load Rating: 31.3 Kg Static Load Rating: 20.9 Kg
Part Number: P-6003A-AGL Plastic Bearings - 17x35x8 mm - Acetal with Glass Balls Out of Stock \| Backorder Now \| Orders can be expected around Mon, Sep 01, 2025 Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Each
ID (d)	OD (D)	Width (B)	Flange Diameter	Indicative Image
ID (d) 17.000 mm _{+ 0.076 / - 0.000} (Equiv. 0.669 in.)	OD (D) 35.000 mm _{+ 0.000 / - 0.102} (Equiv. 1.378 in.)	Width (B) 8.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.315 in.)
Material: Acetal with Glass Balls Max RPM in Air: 1069 Notes: Unlubricated Type: Radial Dynamic Load Rating: 31.3 Kg Static Load Rating: 20.9 Kg
Part Number: P-6003A-AGL Plastic Bearings - 17x35x8 mm - Acetal with Glass Balls Out of Stock \| Backorder Now \| Orders can be expected around Mon, Sep 01, 2025 Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Each View the product page first if you are unsure.
P-6003A-AGL --- Plastic Bearings - 17x35x8 mm - Acetal with Glass Balls P-6003A-AGL --- Plastic Bearings - 17x35x8 mm - Acetal with Glass Balls Regular price $38.77 AUD Regular price Sale price $38.77 AUD Unit price per Out of stock! Backorder Now
ID (d) 17.000 mm _{+ 0.076 / - 0.000} (Equiv. 0.669 in.)	OD (D) 35.000 mm _{+ 0.000 / - 0.102} (Equiv. 1.378 in.)	Width (B) 10.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.394 in.)
Material: Acetal with Glass Balls Max RPM in Air: 1069 Notes: Unlubricated Type: Radial Dynamic Load Rating: 31.3 Kg Static Load Rating: 20.9 Kg
Part Number: P-6003-AGL Plastic Bearings - 17x35x10 mm - Acetal with Glass Balls 12 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $29.77 AUD Regular price Sale price $29.77 AUD Unit price per Each
ID (d) 17.000 mm _{+ 0.076 / - 0.000} (Equiv. 0.669 in.)	OD (D) 35.000 mm _{+ 0.000 / - 0.102} (Equiv. 1.378 in.)	Width (B) 10.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.394 in.)
Material: Acetal with Glass Balls Max RPM in Air: 1069 Notes: Unlubricated Type: Radial Dynamic Load Rating: 31.3 Kg Static Load Rating: 20.9 Kg
Part Number: P-6003-AGL Plastic Bearings - 17x35x10 mm - Acetal with Glass Balls 12 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $29.77 AUD Regular price Sale price $29.77 AUD Unit price per Each View the product page first if you are unsure.
P-6003-AGL --- Plastic Bearings - 17x35x10 mm - Acetal with Glass Balls P-6003-AGL --- Plastic Bearings - 17x35x10 mm - Acetal with Glass Balls Regular price $29.77 AUD Regular price Sale price $29.77 AUD Unit price per 12 Available Now
ID (d) 17.000 mm _{+ 0.076 / - 0.000} (Equiv. 0.669 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 14.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.551 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6303-AGL Plastic Bearings - 17x47x14 mm - Acetal with Glass Balls 2 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $37.41 AUD Regular price ~~$68.84 AUD~~ Sale price $37.41 AUD Unit price per Each
ID (d) 17.000 mm _{+ 0.076 / - 0.000} (Equiv. 0.669 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 14.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.551 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6303-AGL Plastic Bearings - 17x47x14 mm - Acetal with Glass Balls 2 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $37.41 AUD Regular price ~~$68.84 AUD~~ Sale price $37.41 AUD Unit price per Each View the product page first if you are unsure.
P-6303-AGL --- Plastic Bearings - 17x47x14 mm - Acetal with Glass Balls Sale P-6303-AGL --- Plastic Bearings - 17x47x14 mm - Acetal with Glass Balls Regular price $37.41 AUD Regular price ~~$68.84 AUD~~ Sale price $37.41 AUD Unit price per 2 Available Now Sale
ID (d) 20.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.787 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 14.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.551 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6204-AGL Plastic Bearings - 20x47x14 mm - Acetal with Glass Balls 3 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $30.41 AUD Regular price ~~$55.93 AUD~~ Sale price $30.41 AUD Unit price per Each
ID (d) 20.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.787 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 14.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.551 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6204-AGL Plastic Bearings - 20x47x14 mm - Acetal with Glass Balls 3 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $30.41 AUD Regular price ~~$55.93 AUD~~ Sale price $30.41 AUD Unit price per Each View the product page first if you are unsure.
P-6204-AGL --- Plastic Bearings - 20x47x14 mm - Acetal with Glass Balls Sale P-6204-AGL --- Plastic Bearings - 20x47x14 mm - Acetal with Glass Balls Regular price $30.41 AUD Regular price ~~$55.93 AUD~~ Sale price $30.41 AUD Unit price per 3 Available Now Sale
ID (d) 20.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.787 in.)	OD (D) 52.000 mm _{+ 0.000 / - 0.152} (Equiv. 2.047 in.)	Width (B) 15.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.591 in.)
Material: Acetal with Glass Balls Max RPM in Air: 724 Notes: Unlubricated Type: Radial Dynamic Load Rating: 41.7 Kg Static Load Rating: 27.7 Kg
Part Number: P-6304-AGL Plastic Bearings - 20x52x15 mm - Acetal with Glass Balls 1 Available Now \| Further orders can be expected around Mon, Sep 22, 2025 Regular price $59.95 AUD Regular price ~~$110.48 AUD~~ Sale price $59.95 AUD Unit price per Each
ID (d) 20.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.787 in.)	OD (D) 52.000 mm _{+ 0.000 / - 0.152} (Equiv. 2.047 in.)	Width (B) 15.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.591 in.)
Material: Acetal with Glass Balls Max RPM in Air: 724 Notes: Unlubricated Type: Radial Dynamic Load Rating: 41.7 Kg Static Load Rating: 27.7 Kg
Part Number: P-6304-AGL Plastic Bearings - 20x52x15 mm - Acetal with Glass Balls 1 Available Now \| Further orders can be expected around Mon, Sep 22, 2025 Regular price $59.95 AUD Regular price ~~$110.48 AUD~~ Sale price $59.95 AUD Unit price per Each View the product page first if you are unsure.
P-6304-AGL --- Plastic Bearings - 20x52x15 mm - Acetal with Glass Balls Sale P-6304-AGL --- Plastic Bearings - 20x52x15 mm - Acetal with Glass Balls Regular price $59.95 AUD Regular price ~~$110.48 AUD~~ Sale price $59.95 AUD Unit price per 1 Available Now Sale
ID (d) 25.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.984 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 8.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.315 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6005A-AGL Plastic Bearings - 25x47x8 mm - Acetal with Glass Balls 6 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $36.50 AUD Regular price ~~$67.06 AUD~~ Sale price $36.50 AUD Unit price per Each
ID (d) 25.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.984 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 8.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.315 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6005A-AGL Plastic Bearings - 25x47x8 mm - Acetal with Glass Balls 6 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $36.50 AUD Regular price ~~$67.06 AUD~~ Sale price $36.50 AUD Unit price per Each View the product page first if you are unsure.
P-6005A-AGL --- Plastic Bearings - 25x47x8 mm - Acetal with Glass Balls Sale P-6005A-AGL --- Plastic Bearings - 25x47x8 mm - Acetal with Glass Balls Regular price $36.50 AUD Regular price ~~$67.06 AUD~~ Sale price $36.50 AUD Unit price per 6 Available Now Sale
ID (d) 25.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.984 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 12.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.472 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6005-AGL Plastic Bearings - 25x47x12 mm - Acetal with Glass Balls 18 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $72.86 AUD Regular price Sale price $72.86 AUD Unit price per Each
ID (d) 25.000 mm _{+ 0.102 / - 0.000} (Equiv. 0.984 in.)	OD (D) 47.000 mm _{+ 0.000 / - 0.127} (Equiv. 1.85 in.)	Width (B) 12.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.472 in.)
Material: Acetal with Glass Balls Max RPM in Air: 840 Notes: Unlubricated Type: Radial Dynamic Load Rating: 35.4 Kg Static Load Rating: 23.6 Kg
Part Number: P-6005-AGL Plastic Bearings - 25x47x12 mm - Acetal with Glass Balls 18 Available Now \| Further orders can be expected around Mon, Sep 01, 2025 Regular price $72.86 AUD Regular price Sale price $72.86 AUD Unit price per Each View the product page first if you are unsure.
P-6005-AGL --- Plastic Bearings - 25x47x12 mm - Acetal with Glass Balls P-6005-AGL --- Plastic Bearings - 25x47x12 mm - Acetal with Glass Balls Regular price $72.86 AUD Regular price Sale price $72.86 AUD Unit price per 18 Available Now
ID (d) 30.000 mm _{+ 0.102 / - 0.000} (Equiv. 1.181 in.)	OD (D) 62.000 mm _{+ 0.000 / - 0.152} (Equiv. 2.441 in.)	Width (B) 16.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.63 in.)
Material: Acetal with Glass Balls Max RPM in Air: 729 Notes: Unlubricated Type: Radial Dynamic Load Rating: 41.7 Kg Static Load Rating: 27.7 Kg
Part Number: P-6206-AGL Plastic Bearings - 30x62x16 mm - Acetal with Glass Balls 457 Available Now \| Item Discontinued - Up to 457 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $42.79 AUD Regular price ~~$96.53 AUD~~ Sale price $42.79 AUD Unit price per Each
ID (d) 30.000 mm _{+ 0.102 / - 0.000} (Equiv. 1.181 in.)	OD (D) 62.000 mm _{+ 0.000 / - 0.152} (Equiv. 2.441 in.)	Width (B) 16.000 mm _{+ 0.127 / - 0.000} (Equiv. 0.63 in.)
Material: Acetal with Glass Balls Max RPM in Air: 729 Notes: Unlubricated Type: Radial Dynamic Load Rating: 41.7 Kg Static Load Rating: 27.7 Kg
Part Number: P-6206-AGL Plastic Bearings - 30x62x16 mm - Acetal with Glass Balls 457 Available Now \| Item Discontinued - Up to 457 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $42.79 AUD Regular price ~~$96.53 AUD~~ Sale price $42.79 AUD Unit price per Each
P-6206-AGL --- Plastic Bearings - 30x62x16 mm - Acetal with Glass Balls Sale P-6206-AGL --- Plastic Bearings - 30x62x16 mm - Acetal with Glass Balls Regular price $42.79 AUD Regular price ~~$96.53 AUD~~ Sale price $42.79 AUD Unit price per 457 Available Now Sale
