Collection: Bearings - Conveyor
- Bearings (With Images)
- Conveyor
28 Products in this selection
Combined category including various types of Conveyor Bearings.
- This range includes plastic and stainless steel bearings for conveyor lines using hexagonal shafting.
- Both types are ideal for coping with regular washdown.
- Loads and Speeds are for reference only. Testing recommended.
Small Parts & Bearings
Additional resources:
A more comprehensive listing may be found on the MBA Minibearings main store at Bearings - Conveyor.
Additional resources:
A more comprehensive listing may be found on the MBA Minibearings main store at Bearings - Conveyor.
| Hex Bore (A) | OD (B) | Width (C) | Width (D) | Flange Dia. (E) | Flange Width (F) |
Indicative Image |
|---|---|---|---|---|---|---|
|
Hex Bore (A)
17.45
mm + 0.30 / - 0.00
(Equiv. 0.687 in.) |
OD (B)
57.40
mm +/- 0.080 (Equiv. 2.26 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
Flange Dia. (E)
60.20
mm |
Flange Width (F)
2.54
mm |
|
|
Material: Polypropylene Races with Stainless Steel 316 Balls
Max Speed Unloaded: 672 RPM
Category: Bearings - Conveyor - Double Row |
||||||
|
Part Number: CB-574-175H-18-PD (10 Pcs) Conveyor Bearings - 17.45x57.4x17.78 mm / 23.62 mm Double Row - Polypropylene Races with Stainless Steel 316 Balls
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$343.23 AUD
Regular price
Unit price
per
Per 10
|
||||||
| Hex Bore (A) | OD (B) | Width (C) | Width (D) |
Indicative Image |
||
|
Hex Bore (A)
17.45
mm + 0.30 / - 0.00 (Equiv. 0.687 in.) |
OD (B)
57.40
mm +/- 0.080 (Equiv. 2.26 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
|
||
|
Material: Polypropylene Races with Stainless Steel 316 Balls
Flange Dia. (E): 60.20 mm
Flange Width (F): 2.54 mm
Max Speed Unloaded: 672 RPM
Category: Bearings - Conveyor - Double Row |
||||||
|
Part Number: CB-574-175H-18-PD (10 Pcs) Conveyor Bearings - 17.45x57.4x17.78 mm / 23.62 mm Double Row - Polypropylene Races with Stainless Steel 316 Balls
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$343.23 AUD
Regular price
Unit price
per
Per 10
|
||||||
|
||||||
|
Hex Bore (A)
17.45
mm + 0.30 / - 0.00
(Equiv. 0.687 in.) |
OD (B)
57.40
mm +/- 0.080 (Equiv. 2.26 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
Flange Dia. (E)
60.20
mm |
Flange Width (F)
2.54
mm |
|
|
Material: Stainless Steel 316 Balls and Races
Max Speed Unloaded: 672 RPM
Category: Bearings - Conveyor - Double Row |
||||||
|
Part Number: CB-574-175H-18-6D (25 Pcs) Conveyor Bearings - 17.45x57.4x17.78 mm / 23.62 mm Double Row - Stainless Steel 316 Balls and Races
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$5,725.59 AUD
Regular price
Unit price
per
Per 25
|
||||||
|
Hex Bore (A)
17.45
mm + 0.30 / - 0.00 (Equiv. 0.687 in.) |
OD (B)
57.40
mm +/- 0.080 (Equiv. 2.26 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
|
||
|
Material: Stainless Steel 316 Balls and Races
Flange Dia. (E): 60.20 mm
Flange Width (F): 2.54 mm
Max Speed Unloaded: 672 RPM
Category: Bearings - Conveyor - Double Row |
||||||
|
Part Number: CB-574-175H-18-6D (25 Pcs) Conveyor Bearings - 17.45x57.4x17.78 mm / 23.62 mm Double Row - Stainless Steel 316 Balls and Races
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$5,725.59 AUD
Regular price
Unit price
per
Per 25
|
||||||
|
||||||
|
Hex Bore (A)
17.46
mm + 0.30 / - 0.00
(Equiv. 0.687 in.) |
OD (B)
52.22
mm +/- 0.080 (Equiv. 2.056 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
Flange Dia. (E)
58.93
mm |
Flange Width (F)
2.54
mm |
|
|
Material: Stainless Steel 316 Balls and Races
Max Speed Unloaded: 840 RPM
Category: Bearings - Conveyor - Single Row |
||||||
|
Part Number: CB-522-175H-18-6S (25 Pcs) Conveyor Bearings - 17.46x52.22x17.78 mm / 23.62 mm Single Row - Stainless Steel 316 Balls and Races
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$3,976.50 AUD
Regular price
Unit price
per
Per 25
|
||||||
|
Hex Bore (A)
17.46
mm + 0.30 / - 0.00 (Equiv. 0.687 in.) |
OD (B)
52.22
mm +/- 0.080 (Equiv. 2.056 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
|
||
|
Material: Stainless Steel 316 Balls and Races
Flange Dia. (E): 58.93 mm
Flange Width (F): 2.54 mm
Max Speed Unloaded: 840 RPM
Category: Bearings - Conveyor - Single Row |
||||||
|
Part Number: CB-522-175H-18-6S (25 Pcs) Conveyor Bearings - 17.46x52.22x17.78 mm / 23.62 mm Single Row - Stainless Steel 316 Balls and Races
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$3,976.50 AUD
Regular price
Unit price
per
Per 25
|
||||||
|
||||||
|
Hex Bore (A)
17.46
mm + 0.30 / - 0.00
(Equiv. 0.687 in.) |
OD (B)
57.40
mm +/- 0.080 (Equiv. 2.26 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
Flange Dia. (E)
60.20
mm |
Flange Width (F)
2.54
mm |
|
|
Material: Stainless Steel 316 Balls and Races
Max Speed Unloaded: 840 RPM
Category: Bearings - Conveyor - Single Row |
||||||
|
Part Number: CB-574-175H-18-6S Conveyor Bearings - 17.46x57.4x17.78 mm / 23.62 mm Single Row - Stainless Steel 316 Balls and Races
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$228.59 AUD
Regular price
Unit price
per
Each
|
||||||
|
Hex Bore (A)
17.46
mm + 0.30 / - 0.00 (Equiv. 0.687 in.) |
OD (B)
57.40
mm +/- 0.080 (Equiv. 2.26 in.) |
Width (C)
17.78
mm (Equiv. 0.7 in.) |
Width (D)
23.62
mm |
|
||
|
Material: Stainless Steel 316 Balls and Races
Flange Dia. (E): 60.20 mm
Flange Width (F): 2.54 mm
Max Speed Unloaded: 840 RPM
Category: Bearings - Conveyor - Single Row |
||||||
|
Part Number: CB-574-175H-18-6S Conveyor Bearings - 17.46x57.4x17.78 mm / 23.62 mm Single Row - Stainless Steel 316 Balls and Races
Out of Stock | Backorder Now | Orders can be expected around Fri, Aug 29, 2025 Regular price
$228.59 AUD
Regular price
Unit price
per
Each
|
||||||
|
||||||
